Installation Instructions

394
7.
AB
1Automatic Sound 1 Speaker out RR+
2 Radio Mute 2 Speaker out RR-
3 Sub out 3 Speaker out RF+
4Permanent +12V 4 Speaker out RF-
5Aut. antenna 5 Speaker out LF+
6 Illumination 6 Speaker out LF-
7 Kl.15/Ignition 7 Speaker out LR+
8 Ground 8 Speaker out LR-
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
C
B
A
1
4
7
10
13
16
19
3
6
9
12
15
18
2
58
11
14
17
20
C-1 C-2 C-3
2
D
1
3
4
5
6
7
8
9
10
Equalizer Amplifier
CD-Changer
Remote
Control
Telefon NF in
D
1AUX 2- NF L
2 AUX 2- NF R
3AUX 2- REF
4NC
5 NC
6NC
7NC
8NC
9 MIC GND
10 MIC INPUT
C
C1 C2 C3
1 Line Out LR 7 Telefon NF in + 13 Bus (TMC) - In
2 Line Out RR 8 Telefon NF in – 14 Bus (TMC) - Out
3 Line Out Masse / Ground 9 Radio Mute 15 Permanent +12V
4 Line Out LF 10 FB +12V / RC +12V 16 +12V
5 Line Out RF 11 Fernbedienung / Remote Control 17 Bus(TMC)-Masse/GND
6 +12V Amplifier 12 FB - Masse / RC - GND 18 AF -AUX 1 Masse/GND
19 CDC IN L (AUX 1NF L)
20 CDC IN R (AUX 1NF R)
