User Manual

5
EN
* Old versions of the DX4e and DX5e (with 2 Position Channel 5 Switches) are not recommended for the 350 QX. Only Smart Mode and Agility Mode will be
available with GPS On.
Transmitter Model
Type
Reverse Setup
Throttle Cut Setup
Mode Setup Switch Positions Throttle Cut Return Home Dual Rate
Switch
High Rate
Low Rate
DX7S Acro
AUX1-R Others-N
Set To: Trainer
Channel Assign: Move Gear to F MODE (F MODE:GEAR) Leave FLAPS as AUX1 Set All Others to INH MIX 1: GER > GER RATE: 0% -100% OFFSET: 0%; TRIM: INH; SW: Mix0
F MODE (0) = SMART Mode
Press Trainer
FLAP Pos 0 = OFF FLAP Pos 2 = Return Home
ELEV-AIL D/R 100% 70%
F MODE (1) = Stability Mode F MODE (1); HOLD (1) = Agility Mode
DX8 Acro
AUX1-R Others-N
Set To: Trainer
Switch Select: F-Mode to Gear; Flap to Aux 1 All Others to INH
F MODE (0) = SMART Mode
Press Trainer/ Bind
FLAP Pos 0 = OFF FLAP Pos 2 = Return Home
ELEV-AIL D/R 100% 70%
F MODE (1) = Stability Mode F MODE (2) = Agility Mode
DX18 Acro
AUX1-R Others-N
Set To: I (BIND)
Channel Assign: NEXT 1-4: N/A 5 Gear: B 6 AUX1: D 7 AUX2: I 8-10: INH
B (0) = SMART Mode
Press I (BIND)
D (FLAP) Pos 0 = OFF D (FLAP) Pos 2 = Return Home
ELEV-AIL D/R 100% 70%
B (1) = Stability Mode B (2) = Agility Mode
