Developer Information
59
Command Combinations
You can combine the parameters into a single command, for example:
play: speed: 200 loop: true single clip: true
Or for configuration:
configuration: video input: SDI audio input: XLR
Or to switch to the second disk, but only play NTSC clips:
slot select: slot id: 2 video format: NTSC
Using XML
While you can use the Terminal to talk to HyperDeck, if you are writing software you can use XML to confirm
the existence of a specific command based on the firmware of the HyperDeck you are communicating
with. This helps your software user interface adjust to the capabilities of the specific HyperDeck model and
software version.
Protocol Details
Connection
The HyperDeck Ethernet server listens on TCP port 9993.
Basic syntax
The HyperDeck protocol is a line oriented text protocol. Lines from the the server
will be separated by an ascii CR LF sequence. Messages from the client may be
separated by LF or CR LF.
New lines are represented in this document as a "↵" symbol.
Command syntax
Command parameters are usually optional. A command with no parameters is
terminated with a new line:
{Command name}↵
If parameters are specified, the command name is followed by a colon, then pairs
of parameter names and values. Each parameter name is terminated with a colon
character:
{Command name}: {Parameter}: {Value} {Parameter}: {Value} ...↵
