User Manual

Using Your Favorite Editing Software
33
Adobe Premiere Pro CC
When you install the HyperDeck Software, Blackmagic plug-ins are automatically installed to
Adobe Premiere Pro CC.
Setting up a Blackmagic Design project
Step 1. Launch Premiere Pro.
Step 2. Create a New Project and click on the Scratch Disks tab.
Step 3. Set the desired Location and Name for your project at the bottom of this window.
Step 4. Set the locations for your captured video, captured audio, video previews and audio previews.
Step 5. Set the Capture Format to Blackmagic Capture and click on the Settings button to reveal the
Blackmagic Capture Settings for your project. The Video Standard can be set to NTSC, PAL,
HD720 or HD1080. The Video Format can be uncompressed or compressed. Now click OK.
Step 6. The New Sequence window will appear. To preserve maximum video quality, you'll need to create
a full resolution uncompressed sequence. To do so, click the discovery triangle next to "Blackmagic
Design", select a preset to match the video standard and choose from uncompressed 8 bit YUV,
10 bit YUV or 10 bit RGB. If you don't have the storage space or disk speed for uncompressed
video, choose a JPEG sequence preset for a full resolution, open-standard codec.
Step 7. When you have selected the desired sequence preset, give the sequence a name and click OK.
Adobe Premiere Pro CC
