Using HyperDeck
25
Command Reply No Remote Notes
0x40 0x23 AOutReset Acknowledge Disabled
0x44 0x31 PrerollPreset Acknowledge Disabled
0x40 0x40 AutoModeOff Acknowledge Disabled
ignored, Status bit
remembered
0x40 0x41 AutoModeOn Acknowledge Disabled
ignored, Status bit
remembered
6 - Sense Request
0x61 0x0A TimeCodeGenSense
Request for Gen TC GenTCData Enabled
Timer1Sense Timer1Data Enabled
UserBitsVITCTimeSense UserBitsVITCTimeData Enabled
LTCUserBitsTimeSense LTCUserBitsTimeData Enabled
VITCUserBitsTimeSense VITCUserBitsTimeData Enabled
0x60 0x10 InDataSense InData Enabled
0x60 0x11 OutDataSense OutData Enabled
0x60 0x12 AInDataSense AInData Enabled
0x60 0x13 AOutDataSense AOutData Enabled
0x61 0x20 StatusSense StatusData Enabled
0x60 0x2E SpeedSense SpeedData Enabled
0x60 0x31 PrerollTimeSense PreRollTimeData Enabled
0x60 0x36 TimerModeSense TimerModeData Enabled
0x60 0x3E RecordInhibitSense RecordInhibitStatus Enabled
Supported RS-422 Commands
