Test Sheet - FD

BEST TEST SERVICE SHENZHEN CO.,LTD Page 13 Of 16
LUMINOUS DISTRIBUTION INTENSITY DATA
NAME:
SPEC.:
MFR.: Blackjack Lighting
TYPE:STL-06P-BL or PC-FD
DIM.:
SUR.:
WEIGHT:
SERIAL No.:
Shielding Angle:
Test:U:120.00V I:0.0893A P:10.384W PF:0.9686 Freq:60.00Hz Lamp Flux:364.394x1 lm
(DEG)

C(DEG)
Table--1 UNIT: cd
0
0 57.7
5 66.6
10 73.6
15 74.6
20 72.4
25 68.9
30 64.9
35 61.1
40 57.4
45 53.5
50 49.7
55 45.7
60 41.8
65 38.0
70 34.3
75 30.8
80 27.6
85 24.8
90 22.7
95 20.8
100 19.1
105 17.6
110 16.2
115 14.9
120 13.7
125 12.5
130 11.4
135 10.3
140 9.13
145 7.99
150 6.82
155 5.63
160 4.44
165 3.22
170 2.00
175 0.55
180 0.00
22.5
57.7
66.9
74.5
75.6
73.3
69.6
65.5
61.5
57.6
53.7
49.6
45.6
41.6
37.7
34.0
30.5
27.2
24.5
22.3
20.4
18.8
17.3
15.9
14.6
13.4
12.3
11.2
10.1
8.96
7.84
6.70
5.54
4.36
3.16
1.96
0.52
0.00
45
57.7
67.6
75.6
76.6
74.2
70.1
65.8
61.6
57.6
53.6
49.5
45.5
41.5
37.6
33.9
30.4
27.1
24.4
22.2
20.4
18.7
17.2
15.9
14.6
13.4
12.3
11.2
10.0
8.94
7.82
6.67
5.51
4.33
3.14
1.94
0.46
0.00
67.5
57.7
68.3
76.4
77.3
74.5
70.2
65.7
61.4
57.3
53.3
49.3
45.4
41.4
37.6
33.9
30.5
27.3
24.6
22.4
20.6
18.9
17.5
16.1
14.8
13.6
12.4
11.3
10.2
9.04
7.90
6.73
5.55
4.36
3.16
1.95
0.41
0.00
90
57.7
68.8
76.9
77.7
74.5
69.9
65.3
61.0
57.0
53.1
49.3
45.4
41.6
37.8
34.2
30.8
27.7
25.0
22.8
21.0
19.3
17.8
16.4
15.1
13.9
12.7
11.5
10.4
9.21
8.03
6.84
5.64
4.42
3.21
1.99
0.25
0.00
112.5
57.7
69.1
77.5
78.0
74.6
69.9
65.1
60.9
56.9
53.2
49.4
45.6
41.8
38.1
34.5
31.1
28.0
25.3
23.1
21.3
19.6
18.1
16.7
15.4
14.1
12.9
11.7
10.5
9.35
8.16
6.94
5.72
4.49
3.26
2.03
0.33
0.00
135
57.7
69.5
77.8
78.3
74.9
70.1
65.4
61.1
57.1
53.4
49.6
45.8
42.0
38.3
34.7
31.3
28.1
25.3
23.2
21.3
19.6
18.1
16.7
15.4
14.1
12.9
11.7
10.5
9.36
8.17
6.97
5.75
4.52
3.29
2.06
0.29
0.00
157.5
57.7
70.1
78.4
78.8
75.3
70.5
65.7
61.3
57.2
53.4
49.5
45.7
41.9
38.1
34.5
31.0
27.8
25.1
22.9
21.0
19.4
17.9
16.5
15.2
13.9
12.7
11.6
10.4
9.28
8.13
6.94
5.74
4.52
3.30
1.38
0.25
0.00
180
57.7
70.8
79.1
79.3
75.7
70.7
65.6
61.1
56.8
52.9
49.0
45.1
41.3
37.6
34.0
30.6
27.4
24.7
22.6
20.7
19.1
17.6
16.2
15.0
13.8
12.6
11.5
10.3
9.18
8.02
6.85
5.67
4.47
3.27
1.59
0.26
0.00
202.5
57.7
71.6
80.1
80.2
76.4
71.2
65.9
61.2
56.9
52.9
49.0
45.1
41.2
37.5
33.9
30.4
27.3
24.5
22.4
20.6
19.0
17.5
16.2
14.9
13.7
12.6
11.4
10.3
9.14
7.98
6.82
5.66
4.47
3.27
1.51
0.30
0.00
225
57.7
71.8
80.6
80.9
77.1
71.9
66.7
61.9
57.6
53.5
49.5
45.6
41.6
37.8
34.1
30.5
27.3
24.5
22.4
20.6
18.9
17.5
16.1
14.8
13.6
12.5
11.4
10.2
9.11
7.97
6.82
5.64
4.47
3.27
1.95
0.21
0.00
247.5
57.7
71.2
80.1
80.7
77.2
72.1
67.0
62.4
58.1
54.0
50.0
46.0
42.0
38.1
34.3
30.7
27.5
24.7
22.5
20.6
19.0
17.5
16.2
14.9
13.7
12.5
11.4
10.3
9.17
8.03
6.86
5.68
4.49
3.29
1.95
0.47
0.00
270
57.7
70.1
78.5
79.2
76.0
71.3
66.6
62.2
58.1
54.1
50.2
46.2
42.3
38.3
34.6
31.1
27.8
25.0
22.8
20.9
19.3
17.8
16.4
15.1
13.9
12.7
11.6
10.5
9.31
8.14
6.96
5.75
4.55
3.33
2.08
0.52
0.00
292.5
57.7
68.8
76.5
77.1
74.1
69.9
65.6
61.5
57.7
53.9
50.1
46.2
42.4
38.6
34.9
31.4
28.2
25.4
23.2
21.3
19.6
18.1
16.7
15.4
14.2
13.0
11.8
10.6
9.45
8.26
7.05
5.82
4.59
3.36
2.10
0.62
0.00
315
57.7
67.5
74.6
75.3
72.6
68.7
64.7
60.9
57.3
53.6
49.9
46.1
42.3
38.6
35.0
31.6
28.4
25.6
23.5
21.6
19.8
18.3
16.9
15.6
14.3
13.1
11.9
10.7
9.51
8.30
7.09
5.86
4.61
3.37
1.79
0.45
0.00
337.5
57.7
66.8
73.7
74.5
72.2
68.6
64.7
61.0
57.3
53.6
49.9
46.1
42.3
38.5
34.8
31.4
28.2
25.4
23.3
21.3
19.6
18.1
16.7
15.4
14.2
12.9
11.8
10.6
9.40
8.22
7.03
5.81
4.59
3.34
1.44
0.53
0.00
C Range: 0 - 360DEG
C Interval: 22.5DEG
Range: 0 - 180DEG
Interval: 1.0DEG


Test Speed: HIGH Test System:EVERFINE GO-R5000_V2 SYSTEM V2.0.366
Temperature:25.6DEG Humidity:67.1%
Test Distance:2.457m [K=1.0000]Operators:David
Test Date:20 June 2018 Remarks:
