Specifications
107
Maximum Input Protection: 1000VDC or 750VAC for all ranges.
Open circuit voltage: Maximum voltage is 13.3 VDC for 120 Ω, 1.2 kΩ, 12 Ω, 12 MΩ and 120 MΩ
ranges.
Maximum voltage is 7 VDC for 120 kΩ and 1.2M ranges.
Continuity
Accuracy ± (% of reading + % of range), 23°C ±5°C
Rate Range Resolution
Full Scale
Reading
Test Current
Accuracy
(1 year)
Fast 1 kΩ 100 mΩ 999.9 1 mA 0.10+0.020
Maximum Input Protection: 1000VDC or 750VAC for all ranges.
Open circuit voltage: <13.3 VDC
Test Current: Approximately 1 mA DC
Threshold resistance: From 1 Ω to 1000 Ω, default of power on is 10 Ω
Diode
Accuracy ± (% of reading + % of range), 23°C ±5°C
Rate Range Resolution
Full Scale
Reading
Test Current
Accuracy
(1 year)
Med
3.0000 V
10.0000 V
10.0000 V
100 μV
100 μV
100 μV
2.9999
10.0000
10.0000
1 mA
100 μA
10 μA
0.030+0.020
0.030+0.020
0.030+0.020
Maximum Input Protection: 1000VDC or 750VAC for all ranges.
