User's Manual

Table 3-2(B)
“Symbologies” Tab(Figure 3-3-3): Select the desired bar code
symbology from the pull-down list and complete the fields.
Please see 3.2.3 Symbologies List for more detail information of each Bar Code.
Field Name Function/Operation
Fixed Length
The length can be
set from 2 to 80
After the selected bar code is enabled, and the three
kinds of length is filled inside these three blank
items. Then, Only the selected bar code with one of
these three kinds of length can be showed the
customer’s application program.
Transmit
Transmit the bar code by adding selected type(s) of
error checking protocol
Verify
Enable/Disable the verification with Checksum.
 “Options” Tab ( Figure3-3-4)
Field Name Function/Operation
Trigger
timeout(sec)
Select a trigger timeout duration(in seconds) from
this pull-down list.(3 sec ~10sec)
Keybd Message
Select from “Type writing” and “Copy & paste”.
Select a method based upon the bar code scanning
application you will use.
Termination
Message
Select the desired termination code from the
pull-down list.<None, CRLF, Space, tab>
Beep after data
collect
Select the numbers of beep tone when scanning.
< 0,1,2 >
Auto Scan
 Select “Disable” to disable the auto scan
function.
 Select/Enable the auto scan duration(in
seconds) from this pull-down list.
< 1,2,3,4,5>
Prefix
Type the desired label prefix in this text
box
Label
Suffix
Type the desired label suffix in this text
box
BarCode
Setting
Default
Tap this tab to return back to the default value for
“Options” applet.
P3-5
