PLUS USER'S GUIDE 53W1 SERIES 220-240V 2 Thank You 3 Safety Instructions 4 Product View 5 Assembly 6-10 Operations 11 Maintenance and Care 12 Troubleshooting 13 Replacement Parts 14 Accessories 15 Guarantee 16 Consumer Care
Thanks for buying a BISSELL deep cleaner We’re glad you purchased a BISSELL deep cleaner. Everything we know about floor care went into the design and construction of this complete, high-tech home cleaning system. Your BISSELL deep cleaner is well made, and we back it with a limited two year guarantee. We also stand behind it with a knowledgeable, dedicated Consumer Care department, so, should you ever have a problem, you’ll receive fast, considerate assistance.
IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should be observed, including the following: Read all instructions before using your deep cleaner. WARNING: To reduce the risk of fire, electric shock, or injury: ■ Do not leave appliance when plugged in. ■ Unplug from electrical socket when not in use and before servicing. ■ Do not modify earthed plug. ■ Use indoors only. ■ Do not allow to be used as a toy.
Product view Spray Trigger Quick Release Cord Wrap Tough Stain Tool Hose Wrap Handle Assembly Power Cord Hose Warning: To reduce the risk of fire and Upper Body electric shock due to internal component damage, use only BISSELL cleaning formulas intended for use with the deep cleaner.
Assembly Your deep cleaner assembles quickly and easily. The only tool you will need for assembly is a Phillips head screwdriver. 1. 2. 3. 4. 5. 6. 7. 8. 1. Slide upper body onto lower body. 2. Secure with screws. 3. Attach hose wrap to upper handle by sliding it up the bottom of the handle until it snaps firmly in place. 4. Slide upper handle into upper body, until it will not go any further and secure with screw. 5. Place solution tank on back of unit. 6. Wrap power cord and flex hose. 7.
Operations Special features Your BISSELL deep cleaner is a home cleaning system that uses a combination of hand hot tap water, BISSELL cleaning formula, brush agitation and suction to safely clean carpets. DirtLifter™ Powerbrush The DirtLifter PowerBrush is designed to enhance cleaning performance. The bristle pattern safely lifts out the deep down dirt while gently grooming carpet fibers. The floating suspension self-adjusts to all carpet heights.
Operations Before you clean continued 4. Pretreating (optional) Pretreat stubborn stains and highly soiled carpet in hallways and other high-traffic areas. 4a. Generously spray BISSELL Stain Pretreat evenly over soiled area. Caution: DO NOT OVER WET CARPET 4b. Wait 3-5 minutes before deep cleaning. Fill the tank 1. 1. Remove the solution tank by lifting it straight up, then away from the lower body. 2. 2. Unscrew the black cap at the bottom of the solution tank. 3.
Operations Empty the collection tank continued 2a. Release collection tank latches (on each side) by pulling up from the bottom of latch and then out. 2a. 2b. 2b. Carefully remove the top of the tank by lifting up on the tank handle. 3. Carry collection tank to a toilet or sink. To empty, pour out contents using opening at back of tank. 4. Rinse collection tank thoroughly and replace on unit. 3. 5. Refill solution tank and continue cleaning.
Operations Cleaning with attachments continued 5. Plug in and turn the power switch to the ON position. 6. Clean by pressing the spray trigger to spray solution onto the area to be cleaned. Slowly move the tool back and forth over the soiled surface. Release the spray trigger to suction dirty water. Continue to clean in the area, working in small sections, until dirt is removed. Caution: Do Not Overwet. 7. When finished cleaning, remove and rinse tool(s) in clean, running water. 8.
Operations Cleaning after use 2a. 1. Unplug the unit. 2. Rinse collection tank thoroughly. 2a. Remove ReadyTools Dial by rotating it halfway between “TOOLS” & “FLOOR CLEANING.” 2b. 2b. 3. 4. 5. 6. 2b. Pop out knob by using the opening on the back of the tank. Rinse and replace knob and collection tank. 3. Remove tank vent & foam filter (located on top of the collection tank) and rinse. 4. Clean nozzle window by lifting latch and removing from machine. Rinse under running water. 5.
Maintenance and care Machine storage For best results, a few simple steps can assure your machine is well maintained after your cleaning is complete. 1. Wrap power cord around Quick Release Cord Wrap™ on side of the machine. 2. Wipe all surfaces with a soft cloth. Store cleaner upright in a protected, dry area. NOTE: You may have cleaning solution remaining in the solution tank. You may store your machine this way for the next cleaning task, but never keep dirty water in the collection tank.
Troubleshooting Reduced Spray OR No Spray in Upright Mode Possible causes Remedies 1. Solution tank empty 1. Refill tank with water and formula 2. Lint screen on solution tank cap clogged 2. Soak solution tank cap in warm water and then rinse under running water Reduce Spray or No Spray Attachment Possible causes Remedies 1. Solution tank empty 1. Refill tank with water and formula 2. Spray nozzle clogged 2. Clean spray nozzle by rinsing tool under water 3. Pump needs priming 3.
Replacement parts Below please find a list of common replacement parts. While not all of these parts may have come with your specific machine, all are available to you for purchase, if desired. Item 1 2 3 4 5 6 7 8 9 10 Part No.
Accessories Item Part No. 1 2 3 4 5 6 7 *Not Part Name 203-6651 3” Tough Stain Tool 203-6652 Powered TurboBrush™ Hand Tool 203-6653 4” Upholstery Tool 203-6654 6” Stair Tool 203-6655 Spraying Crevice Tool 203-7412 Deep Reach™ Tool 203-5683 Hard Floor Tool, all parts are included with every model. 1 2 6 7 3 4 5 Cleaning Formula: Refer to bottom of page 4 of this guide for a full selection of cleaning formula available for purchase. 14 w w w. b i s s e l l .
Guarantee This Guarantee only applies outside of the USA and Canada. It is provided by BISSELL International Trading Company BV (“BISSELL”). This Guarantee is provided by BISSELL. It gives you specific rights. It is offered as an additional benefit to your rights under law. You also have other rights under law which may vary from country to country. You can find out about your legal rights and remedies by contacting your local consumer advice service.
BISSELL consumer care If your BISSELL product should require service: Call BISSELL Consumer Care at the numbers below and we will give you the location of a BISSELL Authorized Service Center in your area. If you have questions about your guarantee or need replacement parts please contact the numbers below. For UK inquiries: Monday - Thursday 9 am - 5 pm Friday 9 am - 4 pm BISSELL Homecare (Overseas) Inc.
