Instruction manual
For Body – BAND 2
Wash and dry skin before use. Connect the output wire
to the gel pads. Connect the other end of the output
wire to the output jack on ElectroFlex. Remove the
protective film from the adhesive pads. Attach the gel
pads to the skin. Press the on/off button for 3 seconds
to turn on the unit and adjust the stimulating mode
and ou
tput intensity to the desired level. (The display
will show the mode and level that you selected and
start to count down).
Plug the 2 cables into the cable jack at the side of the
unit. (See Figure 6).
Connect pin of the cable to the gel pad. (See Figure 7).
Remove the protective film from the gel pad, and
attached the 4 pads to the area of the body you wish
to treat.
Repeat operation as in foot instructions, adjust the
intensity using Band 2.
Gently increase the intensity set
ting b
y pushing the
button “
︿
”. Or decrease intensity setting by pushing
the button “
﹀
”. (See Figure 8).
The LCD will show the level selected (see Figure 9).
When you reach the desired Level the icon will blink.
To stop the blinking and maintain the intensity press
the “
︿
” button 5 times.
To terminate the massage period, turn off the unit at
anytime by pressing the on/off Button for 3 seconds.
The unit has an auto timer, it will start to count down
from 25 minutes of massage and switc
h o
ff
automatically.
Care of your Gel Pads
Never stick two adhesive pads to each other. Keep the
adhesive gel pads clean, do not expose them to high
temperature or direct sunlight. If the electrode gel pads
are insufficiently adhesive or dirty, wipe with a damp
cloth or change for new ones. Replacement parts will
be available directly from BioEnergiser or your
distributor.
Do not clea
n t
he electrode gel pads with any chemical.
ALWAYS try and protect the gel pads store on the gel
pad protector when not in use, as illustrated.
BAND1
BAND2
Jack A
Jack B
Connect with the supplied AC/DC Power Adapter
Plug the DC plug of the power supply into the socket
on the side of ElectroFlex (see Figure 10. Plug in power
adaptor to a suitable wall socket. (Make sure that the
input voltage of the wall socket is suitable for the
supplied adaptor).
Inserting Batteries
If you want to use the ElectroFlex with battery power
instead of the supplied main adaptor, the battery
compartment is located on the underside of the unit.
Remove the battery cover from the unit by removing
the screw with a screwdriver. Insert three new 1.5V size
C batteries with the + and - marks correctly aligned.
Do not mix different types of
batteries or an old battery with a new one. To prevent
the risk of leakage or explosions, never recharge the
batteries, apply heat or take them apart.
When not using batteries, remove them to prevent
battery drainage. If liquid leaks from the batteries, throw
them away. Tho
roughly c
lean the battery compartment
with a dry cloth.
Changing the Sole Massage Roller
The roller is fixed into position between the two
locking locators. These push in to the main body of
the ElectroFlex to hold the sole massage roller firmly
in place.
To Remove the locking locators you will need to
squeeze the locator on the outside face this will push
the locking locator out of its fixed position and allow
you to remove and change t
he r
oller.
Jack A
Jack B
