Instruction manual
Electro Magnetic Compatibility (EMC)
ElectroFlex needs special precautions regarding EMC
and needs to be installed and put into service
according to the EMC information provided in the
Portable and mobile RF communications equipment
can affect ElectroFlex .
that the use of acces
sories, t
ransducers and
cables other than those specified with the exception
of transducers and cables sold by the manufacturer of
the ElectroFlex as replacement parts for internal
components, may result in increased EMISSIONS or
decreased IMMUNITY of the ElectroFlex .
the ElectroFlex should not be used adjacent
to or stacked with other equipment.
Guidance and manufacturer’s declaration – electromagnetic emissions
The ElectroFlex is intended for use in th
e e
lectromagnetic environment specified below. The customer or the user of
the ElectroFlex should assure that it is used in such an environment.
RF emissions CISPR 11 Group 1 The ElectroFlex uses RF energy only for its
internal function. Therefore, its RF emissions are
very low and are not likely to cause any
interference in nearby electronic equipment.
RF emissions CISPR 11 Class B The ElectroFlex is suitable for use in all
establishments, including domestic
Harmonic emissions IEC 61000-3-2 CLASS A establishments and those directly connected to
the public low-voltage power supply network
Voltage fluctuations/flicker emissions IEC 61000-3-3 Complies that supplies buildings used for domestic
purposes.
5. Guidance and Manufacturer’s Declaration – Electromagnetic Immunity
The ElectroFlex is intended for use in the electromagnetic environment specified below. The customer or the user of
the ElectroFlex should assure that it is used in such an environment.
Electrostatic ±6 kV contact ±6 kV contact Floors should be wood, concrete or ceramic tile.
discharge (ESD) ±8 kV air ±8 kV air If floors are covered with synthetic material, the
IEC 61000-4-2 relative humidity should be at least 30 %.
Electrical fast ±2 kV for power ±2 kV for power Mains power quality should be that of a typical
transient/burst supply lines supply lines commercial or hospital environment.
IEC 61000-4-4 ±1kV for ±1kV for
input/output input/output
lines lines
Surge ±1 kV line(s) ±1 kV line(s) Mains power quality should be that of a typical
IEC 61000-4-5 and neutral and neutral commercial or hospital environment.
Voltage dips, short <5 % UT <5 % UT Mains power quality should be that of a typical
interruptions and (>95 % dip in UT) (>95 % dip in UT) commercial or hospital environment. If a dips or an
voltage variations for 0,5 cycle for 0,5 cycle interruption of mains power occurs, the current of the
on power supply 40 % UT 40 % UT ElectroFlex may be dropped off from normal level, it
input lines (60 % dip in UT) (60 % dip in UT)
may b
e necessary to use uninterruptable power
IEC 61000-4-11 for 5 cycles for 5 cycles supply or a battery
70 % UT 70 % UT
(30 % dip in UT) (30 % dip in UT)
for 25 cycles for 25 cycles
<5 % UT <5 % UT
(>95 % dip in UT) (>95 % dip in UT)
for 5s for 5s
Power frequency 3 A/m Not applicable Not applicable
(50/60 Hz)
magnetic field
IEC 61000-4-8
UT is the AC mains voltage prior to application of the test level
