User's Manual

Recommended separation distances between portable
and mobile RF communications equipment and the BSC105/BSC205
The BSC105/BSC205 is intended for use in an electromagnetic environment in which
radiated RF disturbances are controlled. The customer or the user of the BSC105/BSC205 can
help prevent electromagnetic interference by maintaining a minimum distance between
portable and mobile RF communications equipment (transmitters) and the BSC105/BSC205
as recommended below, according to the maximum output power of the
communicationsequipment.
Rated maximum
output power of
transmitter
W
Separation distance accordin
g
to frequency of transmitter
M
150 kHz to 80 MHz
d = 1,2 √ P
80 MHz to 800 MHz
d = 1,2 √ P
800 MHz to 2,5 GHz
d = 2,3 √ P
0,01 0,12 0,12 0,23
0,1 0,38 0,38 0,73
1 1,2 1,2 2,3
10 3,8 3,8 7,3
100 12 12 23
For transmitters rated at a maximum output power not listed above, the recommended
separation distance d in metres (m) can be estimated using the equation applicable to the
frequency of the transmitter, where P is the maximum output power rating of the transmitter
in watts (W) according to the transmitter manufacturer.
NOTE 1 At 80 MHz and 800 MHz, the separation distance for the higher frequency range
applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is
affected by absorption and reflection from structures, objects and people.
64
