2 Bio-Scale MT Column Instruction Manual

1.3 Column Speciﬁcations

All wetted parts are bio-compatible (Tefzel, polypropylene,

polyphenyl sulﬁde, borosilicate glass and buna-N rubber) and

resistant to cleaning and sanitation solvents including 1.0 M NaOH

and 25% acetic acid. The column can be used with most common

aqueous buffers and certain organic solvents including alcohols

and acetonitrile. Do not use halogenated hydrocarbons, aromatic

solvents, or tetrahydrofuran (THF). A detailed solvent compatibility

table is given in Section 4.

Table 1. Column Characteristics.

MT2 MT5 MT10 MT20

Column

Volume, ml

1.9 – 2.3 4.6 – 5.7 9.5 – 11.3 19.4 – 21.9

Column

Dimension, mm

7 x 50 – 60 10 x 59 – 72 12 x 84 – 100 15 x 110 – 124

Maximum

Operating

Pressure, psi

1, 000 750 600 500

1145 psi = 1 MPa. 14.5 psi = 1 bar. Packing material may not withstand high

pressures. See packing material manufacturer’s speciﬁcations.
