Specification Sheet

AMERICAS
HAIKUHOME.COM
855-694-2458
CANADA
HAIKUHOME.COM/CA
844-924-4277
AUSTRALIA
HAIKUHOME.COM/AU
1-300-244-277
SINGAPORE
HAIKUHOME.COM/SG
[phone]
MALAYSIA
[phone]
TECHNICAL
SPECIFI CATIONS
Haiku L Series Fans
Technical Specifications
Diameter of fan sweep
52 in. (1.3 m)
Model number
2
White: L3127-X5-PW-00-02-E-S34
Black: L3127-X5-PB-00-02-E-S34
Caramel/White: L3127-X5-PW-00-02-E-F533-S34
Caramel/Black: L3127-X5-PB-00-02-E-F533-S34
Cocoa/Black: L3127-X5-PB-00-02-E-F532-S34
Operating voltage 100–120 VAC, 1 Φ, 50/60 Hz
Amps (min/max) 0.037/0.42 A
Light output (max) 988 lumens
Light color temperature 2700 K
Light color rendering index 82 CRI
Standard fan heights (A)
11.4 in. (289 mm)
16.4 in. (417 mm)
Weight
4
11 lb (5 kg)
Fan speed (min/max) 7 speeds (60/182 RPM)
Sound level at max speed
5
< 35 dBA
Warranty
Motor: Limited lifetime in the US and Canada
All other components: 1 year in the US and Canada
1
SenseME Technology and the Haiku Home app are supported by Android
™
and iOS
®
.
2
“X” indicates a placeholder number, which varies depending on finish options, where the fan is installed, and other factors.
3
The actual, precise fan weight will vary based on individual component weights and finishing.
5
Actual results of sound measurements in the field may vary due to sound reflective surfaces and environmental conditions.
The 52-inch L Series ceiling fan brings a touch of style to any
living space.
THE CEILING FAN, REINVENTED
• Airfoils — Hybrid resin construction available in matte black,
glossy white, caramel, or cocoa finishes
• Mounting — Universal mount for flat or sloped ceilings 8 feet
(2.4meters) and taller
• Integrated LED Light — Settings include on/o, Sleep mode,
and 16 dimmable light levels; life expectancy of 50,000 hours
• Fan Settings — Whoosh
®
mode (simulates a natural breeze),
Sleep mode, timer, and on/o
• Motor — EC motor with digital inverter drive
• Controls — Handheld remote control, Haiku Home Mobile
App
1
, or voice control through Amazon
®
Alexa-enabled devices
• Environment — Indoor use only
• ENERGY STAR
®
Certified — Performs four times more
eciently than standards require
Handheld
Remote
6 in. (152 mm)
A
52 in. (1.3 m)
© 2016 Delta T Corporation dba Big Ass Solutions. All rights reserved. | An ISO 9001 certified company | RTL-MKTG-22-ENG-01 REV. B | 09/14/16
Lead times may vary.
See warranty for coverage information.
Specifications subject to change without notice.
Black
White
Airfoil Finishes
Caramel Finish
Caramel Cocoa
