PH specsheet

Item No.
Quantity
REACH-IN
WARMING CABINETS
REACH-IN & PASS-THRU,
SOLID DOORS
MODELS:
PH1-1S
PH2-1S
PH1-1S-PT (PASS-THRU)
PH2-1S-PT (PASS-THRU)
Commercial Refrigeration Equipment
General Specification
CABINET CONSTRUCTION
• Exterior—Cabinet front and doors are constructed of heavy gauge stainless
steel for years of extended use.
• Interior— Aluminum interior and sides.
• Optional stainless steel interior and exterior finish available.
• Insulation—Foamed-in-place CFC and HCFC-free polyurethane insulation.
OPERATIONAL INDICATOR PANEL
• Operational indicator panel contains thermometer and adjustable thermostat
control which is accurately calibrated from 80°F to 180°F.
HEATING SYSTEM
• Strip type 750-watt heating elements, operating on 208-240/60/1, having a
total of 1500 watts per compartment.
• Externally mounted blower system maintains even temperature through out
the food zone area.
• Manually controlled humidity vents are provided in the top of the cabinet.
DOORS
• Self-closing doors are securely mounted on rugged cam-lift hinges.
• Each door has a heavy-duty cylinder lock and self-adjusting magnetic gas-
ket.
• Full perimeter of the door opening has a stainless steel door jamb.
• Interior door liner is constructed of heavy gauge stainless steel.
• Doors feature safety grip handles.
SHELVING
• Heavy-duty wire shelves are adjustable in one-inch increments.
• A wide door opening allows the use of optional pan slide types for
12” x 20”, 18” x 26”, and 14” x 18” pans and trays.
MODEL FEATURES
• Adjustable thermostat
• Dial Thermometer
• 6” adjustable, black legs
• Stainless steel case front and door(s)
• Heavy duty cam lift hinges
• Adjustable wire shelves
• Safety grip handles
• Self-closing doors with safety stops
• Door opening accepts 12” x 20”, 18” x 26”, and 14” x 18” pans and trays
• Heavy-duty cylinder locks
• Humidity vent(s) manually operated
• One piece self-adjusting magnetic door gaskets
• Stainless steel door liner
Available From:
*Note: Not all markings may apply to all model variations.
ELECTRICAL
• 15 AMP breaker required for Single Door units
• 20 AMP breaker required for Double Door units
PH2-1S
PH2-1S-PT (PASS THRU)
PH1-1S
PH1-1S-PT (PASS THRU)
