50
TAB.1b
Cooling time increases by 20% if the machine is leaning against the wall.
TAB.4
Min. air circulation
Model Air q.ty
[cfm]
22 lb 650
44 lb
66 lb
88 lb
2.060
2.530
5.300
Model
IR51M-IR51C
(22lb)
IR101L
(44lb L)
IR101S
(44lb S)
IR72S
(66lb)
Gross weight [lb] 276 485 485 551
Net weight [lb] 254 430 430 485
Dimensions 29,3x27,5
x33,5/39,4
31,5x32,7
x68,9
31,5x32,7
x68,9
40,9x39,6
x73,6
Capacity
Mass /cycle [lb] 22 44 44 55
Internal volume [cuft] 2,55 5,52 5,52 13,58
Rails GN1/1
20,8x15,75
GN1/1
20,8x15,75
GN1/1
20,8x15,75
GN2/1
20,8x31,5
Trays 3 6 6 6
Power supply
Voltage [V] 220 ~ 220 ~ 220 ~ 220 ~
Frequency [Hz] 60 60 60 60
Intensity [A] 3,5 5 5 6
Phase 1 ph 3 ph 3 ph 3 ph
Refrigerating unit
Refrigerating power [W] 692 2245 2245 3325
Evaporation temperature [°F] 14 14 14 14
Cooling temperature [°F]
+194÷+38 +194÷+38 +194÷+38 +194÷+38
Cooling time [min] 90 90 90 90
Freezing temperature [°F] - - - -
Freezing time [min] - - - -
Condensation temperature [°F] +130 +130 +130 +130
Max room temperature [°F] +90 +90 +90 +90
Compressor type Ermetic Ermetic Ermetic Ermetic
Fluid refrigerant R404a R404a R404a R404a
Fluid refrigerant qty [lb] 2,2 4 4 4,4
Condesation air Air Air Air Air
Noise [dB] (A) 65 72 72 72
IFR
• • • •
Multi-detector probe
• • • •
