ANNEXES
TAB.1a
Cooling time increases by 20% if the machine is leaning against the wall.
Model
IM51M-IM51C
(22lb)
IM101L
(44lb L)
IM101S
(44lb S)
IM72S
(66lb)
IM102S
(88lb)
Gross weight [lb] 276 485 485 551 706
Net weight [lb] 254 430 430 485 640
Dimensions
29,3x27,5
x33,5/39,4
31,5x32,7
x68,9
31,5x32,7
x68,9
40,9x39,6
x73,6
40,9x39,6
x73,6
Capacity
Mass /cycle [lb] 22 44 44 55 88
Internal volume [cuft] 2,55 5,52 5,52 13,58 13,58
Rails GN1/1
20,8x15,75
GN1/1
20,8x15,75
GN1/1
20,8x15,75
GN2/1
20,8x31,5
GN2/1
20,8x31,5
Trays 3 6 6 6 10
Power supply
Voltage [V] 220 ~ 220 ~ 220 ~ 220 ~ 220 ~
Frequency [Hz] 60 60 60 60 60
Intensity [A] 5,5 12,5 12,5 13,3 17
Phase 1 ph 3 ph 3 ph 3 ph 3 ph
Refrigerating unit
Refrigerating power [W] 617 2011 2011 2011 2400
Evaporation temperature [°F] -22 -22 -22 -22 -22
Cooling temperature [°F]
+194÷+38 +194÷+38 +194÷+38 +194÷+38 +194÷+38
Cooling time [min] 90 90 90 90 90
Freezing temperature [°F]
+194÷0 +194÷0 +194÷0 +194÷0 +194÷0
Freezing time [min] 240 240 240 240 240
Condensation temperature [°F] +130 +130 +130 +130 +130
Max room temperature [°F] +90 +90 +90 +90 +90
Compressor type Ermetic Ermetic Ermetic Ermetic Ermetic
Fluid refrigerant R404a R404a R404a R404a R404a
Fluid refrigerant qty [lb] 3 4,4 4,4 5 7,7
Condesation air Air Air Air Air Air
Noise [dB] (A) 65 72 72 72 72
IFR
• • • • •
Multi-detector probe
• • • • •
