38
Parameter Description
Default
(IM...)
Default
(IR...)
min MAX
S10
Defrost type started through keyboard:
0= electrical or due to compressor stop
1= hot gas
2= air
0 0 0 2
CONFIGURATION
C01 Door input (0 de-activated; 1 activated) 1 1 0 1
C02 Door open polarity 0 0 0 1
C03 Door open alarm delay 2 min 2 min 0 min 60 min
C04 Activates buzzer (0 de-activated; 1 activated) 1 1 0 1
C05 Buzzer duration at the end of quick cooling cycle 10 sec 10 sec 0 600 sec
C06
Temperature difference in the first phase of needle insertion
test (0 = test excluded)
45°F 45°F 0 140°F
C07
Duration of the second phase of needle insertion test (0=test
excluded)
56 sec 56 sec 0 600 sec
C08
Activates condenser probe
0 = no probe
1 = probe
1 1 0 1
C09 Compressor stop delay due to door opening 30 sec 30 sec 0 sec 60 sec
C10 Pressostat alarm detection time 5 sec 5 sec 0 sec 60 sec
C11 High pressare digital input polarity 0 0 0 1
C12 Resistances starting SetPoint 23°F 23°F 14°F 68°F
ADJUSTMENT
R01 Compressor start/stop hysteresis 38°F 38°F 32°F 68°F
R02 Min. interval between 2 compressor starting 2 min 2 min 0 min 30 min
R03 Compressor start delay from card activation 0 sec 0 sec 0 sec 300 sec
R04 Compressor Duty-Cycle time with faulty room probe in storing 10 min 10 min 0 min 90 min
R05 Compressor ON time faulty room in pos. storing 3 min 3 min 0 min 90 min
R06 Compressor ON time with faulty room in neg. storing 8 min 8 min 0 min 90 min
R07 Needle min. temperature for starting quick cooling 158°F 158°F 32°F 194°F
R08 Compressor inhibition temperature 194°F 194°F 32°F 212°F
R09 Compressor Protection function activation time 24 ore 24 ore 0 ore 240 ore
R10 Pulse duration 2 sec 2 sec 1 sec 10 sec
R11 Pause between pulses 4 sec 4 sec 1 sec 10 sec
R12 Number of pulses 3 3 1 20
FANS
F01 Evaporator fans activation hysteresis 36°F
36°F
32°F 68°F
F02 Condenser fans activation hysteresis 36°F
36°F
32°F 68°F
F03 Evaporator fans activation SetPoint 41°F 41°F -58°F 122°F
F04 Condenser fans activation SetPoint 59°F 59°F -58°F 122°F
F05
Evaporator fans during defrost
0 = fans OFF; 1 = fans ON
0 0 0 1
F06
Condenser fans during defrost
0 = fans OFF; 1 = fans ON
0 0 0 1
F07 Fans stop time after defrost 1 min 1 min 0 min 30 min
F08 Condenser fans stop delay 30 sec 30 sec 0 sec 300 sec
F09
Evaporator fans control during quick cooling:
0 = fans always ON
1 = fans thermostated by evaporator temperature
0 0 0 1
F10
Evaporator fans control during storing:
0 = fans in parallel with the compressor
1 = fans thermostated by evaporator temperature
0 0 0 1
F11 Evaporator fans inhibition temperature 158°F 158°F 32°F 194°F
PRINT
PR1 Sampling time 10 min
10 min
1 min 60 min
