Use the keys up e down to select the new value of the parameter
Press enter to confirm your choice
Press menu several times to exit
DESCRIPTION OF PARAMETERS
Parameter Description
Default
(IM...)
Default
(IR...)
min MAX
POSITIVE QUICK COOLING
P01 Room SetPoint in pos. quick cooling, Soft phase 23°F 23°F -22°F 86°F
P02 SetPoint cella in abbattimento Hard -13°F -13°F -40°F 86°F
P03 Needle SetPoint in pos. quick cooling , Soft phase 38°F 38°F -22°F 86°F
P04 Needle SetPoint in Hard quick coolong 68°F 68°F -22°F 86°F
P05 Positive quick cooling duration 90min 90min 0min 900min
P06 Hard phase duration expressed as % in relation to P05 60% 60% 0% 100%
P07 Room SetPoint in pos. storing 36°F 36°F -22°F 86°F
NEGATIVE QUICK COOLING
N01 Room SetPoint in neg, quick cooling -13°F -13°F -40°F 86°F
N02 Needle SetPoint in neg. quick cooling -0°F -0°F -22°F 86°F
N03 Negative quick cooling duration 240min 240min 0min 900min
N04 Room SetPoint in neg. storing -8°F -8°F -40°F 86°F
ALARMS
A01 Temperature alarm hysteresis 36°F 36°F 32°F 122°F
A02 High temperature limit alarm in pos. storing in relation to P07 50°F 50°F 32°F 122°F
A03 Low temperature limit alarm in pos. storing in relation to P07 14°F 14°F -58°F 32°F
A04 High temperature limit alarm in neg. storing in relation to N04 50°F 50°F 32°F 122°F
A05 Low temperature limit alarm in neg. storing in relation to N04 14°F 14°F -58°F 32°F
A06 Temperature alarm delay fron storing or defrost start 60min 60min 0min 300min
A07 Temperature alarm delay 30min 30min 0min 300min
A08 Duration of the buzzer in the alarm mode 1min 1min 0min 240min
DISPLAY
D01 Temperature unit of measurement (0 Celsius; 1 Fahrenheit) 0 0 0 1
D02 Room probe Offset 32°F 32°F 14°F 50°F
D03 BackLight (0 on when pressing a key; 1 always on) 0 0 0 1
DEFROST
S01
Performs defrost on quick cooling start
0 = No; 1 = Yes
0 0 0 1
S02 End-of-defrost temperature 47°F 47°F 14°F 86°F
S03 Defrost max. duration 15 min 15 min 1 min 90 min
S04 Interval between defrosts in storing (0=excluded) 0 ore 0 ore 0 18 ore
S05
Type of defrost:
0= electrical or due to compressor stop
1= hot gas
2= air
2 2 0 2
S06 Dripping time 1 min 1 min 0 min 90 min
S07 Compressor activation delay with hot gas defrost 0 sec 0 sec 0 sec 600 sec
S08 First defrost activation time from storing start (0=excluded) 0 0 0 90 min
S09 Ignores compressor protection delays in defrost 0 0 0 1
