Specifications

33
Microprocessor PIR with
65lb pet immunity &
built-in room-temp alert
PIR1680PT
 45’ x 45’ range
 65lb pet/animal immunity
 Room-temp alert – temperature monitoring
provides auto-alert at 40
0
F - 90
0
F
 Look-down/creep zone
 D.C.I.D. Technology- detect & compare
imaging diagnostics for advanced false and
true alarm detection
 Active self test mode
 Exceptional RFI-/EMI/lightning shielding of
key components
 Lens bank available, including long range,
barrier, and specialty ranges
 Wall or corner mountable
 Tamper supervised
 Form A relay
PIR1680
 Standard model as above, but with
20lb. pet/animal immunity
Advanced 70’ PIR
PIR1710
 70’ x 60’ Broad range coverage perfect for
both residential and commercial
 Features look-down/creep zone
 SSP™ (Signal Selective Processing) for the
easiest and most stable of installations
 Auto temp compensation
 Advanced, EZ-Aim fresnel lenses and lens
bank for optimum detection performance
 Wall or corner mountable
 Excellent EMI-/RMI-/lightning protection
with resilient SMD circuitry
 Tamper supervised
 Form A relay
Economical PIR sensor with
look-down
PIR1510
 30’ x 30’ broad range coverage
 Attractive, super-compact size
 SSP™ (Signal Selective Processing) for the
easiest and most stable installations
 Advanced, EZ-Aim fresnel lenses and lens
bank for optimum detection performance
 Long-range, barrier and specialty lenses
are available to suit all coverage needs
 Wall or corner mountable, with horizontal
and vertical adjust
 EMI-/RMI-/lightning protection with
resilient SMD circuitry
 Form A relay
 PIR1500 version also available, as above,
without look-down/creep zone.
Feature-packed advanced passive infrared sensors
Step 3.
Insert wires
in Quick Wire
terminals and flip
down.
Step 4.
Step 1.
A twist of the
Quick Mount
disk & the unit
embeds
itself in a
corner.
Step 2.
Strip wires and
snap in PC
board.
Replace cover
– It’s a snap!
The pet-immune PIR with
Quick-Catch that profiles
false alarm sources and
virtually installs itself
For decades, NAPCO’s innovative
technology has produced sensors with
superior false alarm discrimination.
Today NAPCO is a leader in smart PIR
technology, P.E.T. immunity, and décor-
enhancing design.
IQ PROFILER™
 50lb. pet immunity (22.7Kg) & superior
false alarm discrimination with unique dual
focal lenses.
 Installation in a snap with patented Quick-
Mount and Quick-Wire terminals
 Maximum range: 50’ x 50’
 New & improved quick-catch mode
 Décor white bi-optic contour case and dual
focal lenses provide exceptional distance
profiling
 Far field lens allows for detection of large
objects and ignores small targets nearby
 Near field lens allows for discrimination of
small targets nearby
 Shielded high-performance aspheric
lenses plus look-down/creep zone
 Sensor chamber prevents insect, draft, and
dust interference.
 20V/m RF-shielded circuitry
IQ VISION Advanced PIR
with “IQ Look” and now
all-white styling
 40’ x 40’ range; 30lb. pet
immunity
 Features look-down/
creep zone
 SSP™ (Signal Selective
Processing) for the
easiest and most stable
of installations
 Auto temp compensation
 Advanced, EZ-Aim
fresnel lenses and lens bank for optimum
detection performance
 Excellent EMI-/RMI-/lightning protection
with resilient SMD circuitry
 Tamper supervised
 Form A relay (Form C option)
 Long-range, barrier and specialty lenses
are available to suit all coverage needs
 Wall or corner mountable, with horizontal
and vertical adjust
