Specifications
Comparison of Gemini
®
panel features & accessories
FEATURES GEMINI ALARM PANELS GEMINI ALARM PANELS
GEM-P400 GEM-P800 GEM-P801 GEM-P816 GEM-P1632 GEM-P1664 GEM-P3200 GEM-P9600 GEM-X255
ZONES ON BOARD
(acts as) 4 (acts as) 6 8 8
8 8 8 8 8
MAX. # ZONES
4 6 9 16
32 64 32/48 96 255
ZONE EXPANSION
(NOTE: Each Custom Alpha Keypad adds 4
Built-in Zones) (2 on RP8LCD)
- 2 Wireless Only Zones 2 Wireless Only Zones
2xGEM-EZM4/8
1xGEM-EZM8
6xGEM-EZM4/8
3xGEM-EZM8
GEM-EZM4/8
GEM-EZM8
3xGEM-EZM8
3xGEM-EZM8
1xGEM-EZM8
GEM-EZM8
31xGEM-EZM8
USER CODES
4 8 8 16
32 64 48 96 195
# OF FIRE ZONES; 2 WIRE FIRE
- 1 2/4 WIRE 1 2/4 WIRE UP TO 16; 2 2-WIRE
UP TO 32; 2 2-WIRE UP TO 64; 2 2-WIRE UP TO 32; 2 2-WIRE
UP TO 96 WITH
UP TO 8 2-WIRE FIRE
UP TO 255 WITH
UP TO 8 2-WIRE FIRE
KEYPADS OR USER
INTERFACES SUPPORTED
4(total)
GEM-RP4 or
GEM-K400
IREMOTEMOD/12
4(total)
GEM-RP8
RP8LCD or
GEM-K800
IREMOTEMOD/12
4(total)
GEM-RP8
RP8LCD or
GEM-K800
IREMOTEMOD/12
7 (total)
GEM-RP1CAe2
RP2ASe2
RP3DGTL or GEM-K1CA
K2AS
K3DGTL or DK1CA
DK3DGTL, K4RF, K4
-PLUS- IREMOTEMOD/12;
iBridge App or IBR-ITAB
Touchscreen
7 (total)
GEM-K1VPS, K1V, RP1CAe2
RP2ASe2
RP3DGTL or GEM-K1CA
K2AS
K3DGTL or DK1CA
DK3DGTL, K4RF, K4
-PLUS- IREMOTEMOD/12;
iBridge App or IBR-ITAB
Touchscreen
7 (total)
GEM-K1VPS, K1V, RP1CAe2
RP2ASe2
RP3DGTL or GEM-K1CA
K2AS or DK1CA
DK3DGTL, K3DGTL
K4RF, K4
-PLUS- IREMOTEMOD/12;
iBridge App or IBR-ITAB
Touchscreen
7 (total)
GEM--RP1CAe2
RP2ASe2
RP3DGTL or GEM-K1CA
K2AS
K3DGTL or DK1CA
DK3DGTL, K4RF, K4
-PLUS- IREMOTEMOD/12;
iBridge App or IBR-ITAB
Touchscreen
15 (total)
GEM--RP1CAe2
RP2ASe2
RP3DGTL or GEM-K1CA
K2AS
K3DGTL or DK1CA
DK3DGTL, K4RF, K4
-PLUS- IREMOTEMOD/12;
iBridge App or IBR-ITAB
Touchscreen
15 (total)
GEM-RP1CAe2
GEM-K1CA
GEM-DK1CA
-PLUS- IREMOTEMOD/12;
iBridge App or IBR-ITAB
Touchscreen
EVENT LOG
- 50 50 256
400 400 800 800 800
# OF AREAS
1 1 1 1
2 4 2 8 8
# OF OUTPUTS
2 2 2 3
3, UP TO 11
(Using RB3008 Relay Modules)
3 UP TO 16
(Using RB3008 Relay Modules)
3, UP TO 27
(Using RB3008 Relay Modules)
3, UP TO 99
(Using RB3008 Relay Modules)
3, UP TO 99
(Using RB3008 Relay Modules)
# OF WIRELESS RECEIVERS
SUPPORTED
2 (GEM-RECVXP8 only) 2 (GEM-RECVXP8 only) 2 (GEM-RECVXP8 only) 2 (GEM-K4RF, RECV32)
2 (GEM-K4RF RECV32/96) 2 (GEM-K4RF RECV32/96) 3 (GEM-K4RF RECV32/96) 4 (GEM-K4RF RECV32/96) 4 (RECV32/96/255)
# WIRELESS POINTS
4 8 8 16
32 64 48 96 255
# WIRELESS KEYFOBS
2 4 4 8
8 8 8 16 16
AUTO ARM
- - - YES
YES YES YES YES YES
OPEN/CLOSE SUPPRESSION
- - - YES
YES YES YES YES YES
AUTO DISARM
- - - -
- - YES YES YES
SCHEDULES
- - - -
- - 255 255 255
LINE CUT DETECT
YES YES YES YES
YES YES YES YES YES
BELL SUPERVISION
YES YES YES YES
YES YES YES YES YES
COMMUNICATION FORMATS
CONTACT ID; 4/2 CONTACT ID; 4/2 CONTACT ID; 4/2 CONTACT ID; 4/2, SIA
CONTACT ID; 4/2, SIA CONTACT ID; 4/2, SIA
CONTACT ID; 4/2, SIA,
Modem II
CONTACT ID
; 4/2
, SIA,
Modem II, (RS232 output option)
CONTACT ID
; 4/2
, SIA,
Modem II, (RS232 output option)
INPUT POWER
16.5 VAC 16.5 VAC 16.5 VAC 16.5 VAC
16.5 VAC 16.5VAC 16.5 VAC 16.5 VAC 16.5 VAC
MAX STANDBY CURRENT
350mA 500mA 650mA 650mA
650mA 650mA 650mA 750mA 750mA
ALARM CURRENT
2 AMPS 2 AMPS 2 AMPS 2 AMPS
2 AMPS 2 AMPS 2 AMPS 2 AMPS 2 AMPS
AVALABLE IN THESE
CONFIGURATIONS
GEM-P400/4
4 Pak of Controls, Keypads & Transformers
GEM-P800
Control, Keypad & Transformer
GEM-P801
Control, RP8 Keypad & Transformer
GEM-P816
Control & Transformer.
GEM-P1632
Control & Transformer
GEMP1664
Control & Transformer
GEM-P3200
Control & Transformer
GEM-P9600
Control & Transformer
GEM-X255
Control & Transformer
GEM-P800PAK
Control, Backlit GEM-RP8 Keypad,
Transformer, Siren, PIR 1500, Jack, Cord,
4AH Battery
GEM-P801ALPHA
Control, Custom Alpha RP8LCD Keypad &
Transformer
816PERFPAK
Control, GEM-RP3DGTL Keypad, Transformer
Also, K816PERFPAK, same but w/
GEMK3DGTL stay away style keypad
1632PROPAK
Control, GEM-RP3DGTL Keypad, Transformer
Also, K1632PROPAK, same but w/
GEMK3DGTL stay away style keypad
GEMP1664VPSPK
4-area control, Multifunction LCD Coded
Talking Keypad w/built in UL siren, occupancy
sensor and 25’Pet PIR (GEM-K1VPS); transf.
Optional Mercantile Housing, H1217 or w/
unit
GEM-P3200M
Optional Mercantile Housing, H1217 or w/
unit GEM-P9600M
GEM-P800PAK2
Control, Backlit GEM-RP8 Keypad,
Transformer, Siren, PIR1680, Jack, Cord, 4AH
Battery
801LCD-SUPERSVR
Control, Custom Alpha RP8LCD Keypad,
Siren, PIR1680PT, Jack, Cord, 4AH Battery &
Transformer
816PERFPAKPLUS
Control, GEM-RP3DGTL Keypad, Transformer,
Siren, PIR, Jack, Cord, 4AH Battery Also,
K816PERFPAK, same but w/ GEMK3DGTL
stay/away style keypad
GEM-K120PAK
Control, Fixed LCD Keypad w/ built in 32pt
RF Receiver and stay/away style keys, Siren,
PIR1680PT, Jack, Cord, 4AH Battery, Transf.
GEMP1664DK1PK
4-area control, in oversized locking enclosure,
Door-Style Keypad (GEM-DK1CA), transf.
801KSUPERSAVER
Control, K800 LED Keypad w/Stay/Away
Keys, Siren, PIR1680PT, Jack, Cord, 4AH
Battery & Transformer
816PREMPAK
Control, GEM-RP1CAe2 Keypad,
Transformer Also, K816PREMPAK, same but
w/ GEM-K1CA stay/away style keypad
1632INTROPAK
Control, GEM-RP1CAe2 Keypad, Transformer
Also, K1632INTROPK, same but w/ GEM-
K1CA stay/away style keypad
IREMOTE64PAK
4-area control, Virtual Keypad Module
(iRemoteMod/12),
Multifunction LCD Coded Talking
Keypad w/built in UL siren, occupancy sensor
and 25’Pet PIR (GEM-K1VPS); transf.
801SUPERSAVERPK
as above but with RP8 LED Keypad with
classic RP Keys
K816RFPAK
Control, GEM-K4RF Keypad w/ built in 32-pt
RF Receiver and stay/away style keys, Transf.
K1632RFPAK
Control, GEM-K4RF Keypad w/ built in 32-pt
RF Receiver and stay/away style keys, Transf.
GEM1632RECVPAK
Control, GEM-RP1CAe2 Keypad,
Conventional 32 Pt. RF Receiver
(GEMRECV32) , Transf.
