Specifications

Gemini Control Panels: Flexible and more options than ever - including remote services Apps, optional WiFi touchscreen internet- & GSM-communications.
22
Gemini X255 is the
expansive hardwire/
wireless control offering
255 fully-programmable
zones, 195 users, fuseless
operation & supports the
full line of top performing
Gemini Wireless
Features:
 8 to 255 hardwired zones or wireless 
zones/pts
 Expandable using 8-zone GEM-EZM8
expansion modules
 Up to 96 fire zones, with 8 2-wire fire
zones
 Up to 8 areas
 Up to 195 user codes with open/close
by user
 3 On-board relay output & 1 prog. lug
 Up to 96 relays
 Supports 4 wireless receivers
 Supports 15 GEMRP1CAE2 or K1CA
keypads
 Up to 2 interior bypass groups
 800 Event log w/ open/close suppress
 Auto arm/disarm
 255 Event scheduler
 GEM-ACCESS access control
compatibility
Gemini P9600 powerful
multi-tasking hybrid
control panel – feature-rich
for security applications
and home automation
integration
Features:
 8 to 96 hardwire zones/points
 Including 8 2-wire fire zones
 Up to 96 user codes
 Up to 8 areas
 3 On-board relay outputs; expandable
to 96
 1 On-board programmable lug
 Up to 4 RF receivers
 Up to 15 keypads
 Up to 2 interior bypass groups
 800 Event log
 Auto arm/disarm
 255 Event scheduler
 GEM-ACCESS access control
compatibility
Gemini P3200, a popular,
all-around 8 zone hybrid
control expandable to 32
zones or 48 wireless points
Features:
 8 to 32 hardwire or wireless zones/
points;
up to 48 RF wireless points
 Including 2 2-wire fire zones
Expandable Gemini
hybrid controls feature:
 Wide choice of designer keypads for
every application and budget (see p. 8)
 Use new iBridge App & Touchscreen/
Tablet for integrated security, climate,
lighting or video control or iRemote
Virtual Keypad (for smartphone or
computer remote interface) in place of
any custom alpha keypad
 Up/downloading, including unique
PC-preset unattended method with
PCD-WINDOWS
 EZ-Programming mode at keypad
 Choice of Gemini RF receivers &
transmitters
 Multi-stage lightning protection
 Event log with open/closes suppression
 Telco line cut supervision
 Fuseless, maintenance-free operation
 Support all major communication formats
plus internet & StarLink GSM Radios,
universal primary/backup communicator
(hi-speed up/downloads from Gemini
Panels)
 Transformer, supplied
