User manual

Specifications
74
Supported 3D signal for HDMI (HDCP) input
Video timing
PC timing
Resolution Timing Horizontal
frequency
(KHz)
Ver ti ca l
frequency
(Hz)
3D Field
Sequential
3D frame
packing
3D top
bottom
3D
side by
side
720 (1440) x
480
480i 15.73 59.94
◎
720 x 480 480p 31.47 59.94
720 (1440) x
576
576i 15.63 50
720 x 576 576p 31.25 50
1280 x 720 720/50p 37.5 50
◎◎
1280 x 720 720/60p 45 60
◎◎
1920 x 1080 1080/
24P
27 24
◎◎
1920 x 1080 1080/
25P
28.13 25
1920 x 1080 1080/
30P
33.75 30
1920 x 1080 1080/50i 28.13 50
◎
1920 x 1080 1080/60i 33.75 60
◎
1920 x 1080 1080/
50P
56.25 50
1920 x 1080 1080/
60P
67.5 60
Resolution Timing Horizontal
frequency
(KHz)
Ver ti ca l
frequency
(Hz)
3D Field
Sequential
3D top
bottom
3D side
by side
640 x 480 VGA_60 59.94 31.469
◎◎◎
VGA_72 72.809 37.861
VGA_75 75 37.5
VGA_85 85.008 43.269
720 x 400 720x400_70 70.087 31.469
800 x 600 SVGA_60 60.317 37.879
◎◎◎
SVGA_72 72.188 48.077
SGVA_75 75 46.875
SVGA_85 85.061 53.674
SVGA_120
(Reduce Blanking)
119.854 77.425
◎
1024 x 768 XGA_60 60.004 48.363
◎◎◎
XGA_70 70.069 56.476
XGA_75 75.029 60.023
XGA_85 84.997 68.667
XGA_120
(Reduce Blanking)
119.989 97.551
◎
1152 x 864 1152 x 864_75 75 67.5
1024 x 576 BenQ Notebook
Timing
60 35.82
1024 x 600 BenQ Notebook
Timing
64.995 41.467
1280 x 720 1280 x 720_60 60 45
◎◎◎
1280 x 720_120 120 90
◎
1280 x 768 1280 x 768_60
(Reduce Blanking)
60 47.396
◎◎◎
1280 x 768_60 59.87 47.776
◎◎◎
