MP510 Digital Projector Mainstream Series User Manual Welcome Downloaded From projector-manual.
Table of contents Important safety instructions ................................... 4 Introduction .............................................................. 8 Projector features .................................................................8 Shipping contents .................................................................8 Projector exterior view..........................................................9 Controls and functions .......................................................
Timing chart ....................................................................... 49 Warranty and Copyright information ................... 50 Limited warranty ............................................................... 50 Copyright ........................................................................... 50 Disclaimer .......................................................................... 50 Regulation statements ............................................. 51 FCC statement .................
1. Important safety instructions Your BenQ projector is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that you follow the instructions mentioned in this manual and marked on the product. Safety Instructions 1. 4 Please read this manual before you operate your projector. Save it for future reference. 2. Do not look straight at the projector lens during operation.
Safety Instructions (Continued) 7. The lamp becomes extremely hot during operation. Allow the projector to cool for approximately 45 minutes prior to removing the lamp assembly for replacement. 8. Do not operate lamps beyond the rated lamp life. Excessive operation of lamps beyond the rated life could cause them to break on rare occasions. 9. Never replace the lamp assembly or any electronic components unless the projector is unplugged. Downloaded From projector-manual.com BenQ Manuals 10.
Safety Instructions (Continued) 12. Do not place this projector in any of the 13. Do not block the ventilation holes. - Do not place this projector on a blanket, following environments. bedding or any other soft surface. - Space that is poorly ventilated or confined. Allow at least 50 cm clearance from walls and free flow of air around the projector. - Do not cover this projector with a cloth or any other item.
Safety Instructions (Continued) 16. 17. Do not step on the projector or place 18. any objects upon it. Besides probable physical damage to the projector, doing so may result in accidents and possible injury. Do not place liquids near or on the projector. Liquids spilled into the 19. projector may cause it to fail. If the projector does become wet, disconnect it from the power supply's wall socket and call BenQ to have the projector serviced.
2. Introduction Projector features The projector integrates high-performance optical engine projection and a user-friendly design to deliver high reliability and ease of use. The projector offers the following features.
Projector exterior view Front/upper side 1 2 6 7 8 3 4 9 5 1. External control panel (See "Projector" on page 10 for details.) Vent (heated air exhaust) Projection lens Quick-release button Lens cap Focus ring Kensington anti-theft lock slot Vent (cool air intake) Front IR remote sensor 2. 3. 4. 5. 6. 7. 8. 9. Rear side See "Connection" on page 17 for details. 12 13 14 15 16 17 11 10 10. 11. 12. 13. 14.
Controls and functions Projector 1 1. 2. 3. 4. 5. 6. 10 2 3 8 9 4 5 6 7 10 5 11 12 Focus ring (See "Fine-tuning the picture 7. clarity" on page 26 for details.) Adjusts the focus of the projected picture. Temperature warning light (See "Indicators" on page 45 for details.) 8. Lights red if the projector’s temperature becomes too high. Power indicator light (See "Indicators" on page 45 for details.) 9. Lights up or flashes when the projector is under operation.
Remote control 5. 1 6 2 7 3 3 4 3 8 6. 7. 9 10 11 8. 5 9. 1. 2. 3. 4. Power (See "Start up" on page 21 and "Shutting down the projector" on page 32 for details.) Turns the projector on or off. 10. Freeze (See "Freezing the picture" on page 31 for details.) Freezes the projected picture. Up, Down, Left, Right (See "Using the OSD menus" on page 34 for 11. details.
Remote control effective range Infra-Red (IR) remote control sensors are located on the front and the back of the projector. The remote control must be held at an angle within 30 degrees perpendicular to the projector's IR remote control sensors to function correctly. The distance between the remote control and the sensors should not exceed 6 meters (~ 20 feet). Make sure that there are no obstacles between the remote control and the IR sensors on the projector that might obstruct the infra-red beam.
3. Positioning your projector Choosing a location Your projector is designed to be installed in one of four possible installation locations: 1. 2. 3. 4. Table in front of screen; Ceiling in front of screen; Table at rear of screen; Ceiling at rear of screen. 1. Front Table Select this location with the projector placed near the floor in front of the screen. This is the most common way to position the projector for quick setup and portability. 2.
Obtaining a preferred projected picture size The distance from the projector lens to the screen, and the video format each factors in the projected picture size. The native resolution of the projector is 800 x 600 pixels, which is a 4 to 3 aspect ratio (expressed as 4:3). To be able to project a complete 16:9 (widescreen) aspect ratio picture, the projector can resize and scale a widescreen picture to the projector's native aspect width.
horizontal distance from the center of the screen (projection distance), and the vertical offset height of the projector from the horizontal edge of the screen (offset). How to determine the position of the projector for a given screen size 1. 2. Select your screen size. Refer to the table and find the closest match to your screen size in the left columns labelled "4:3 Screen Diagonal".
Projection dimensions Refer to "Dimensions" on page 48 for the center of lens dimensions of this projector before calculating the appropriate position. 4:3 Screen Diagonal Screen Center of lens Offset Projection distance 4:3 Screen Diagonal Feet Inches mm 2.5 3 30 36 4 48 5 6 60 72 7 8 84 96 9 108 10 120 12 144 15 180 16.
4. Connection When connecting a signal source to the projector, be sure to: 1. Turn all equipment off before making any connections. 2. Use the correct signal cables for each source. 3. Ensure the cables are firmly inserted. In the connections shown below, some cables may not be included with the projector (see "Shipping contents" on page 8). They are commercially available from electronics stores.
Connecting Video source devices You can connect your projector to various Video source devices that provide any one of the following output sockets: • Component Video • S-Video • Video (composite) You need only connect the projector to a Video source device using just one of the above connecting methods, however each provides a different level of video quality.
Connecting a Component Video source device Examine your Video source device to determine if it has a set of unused Component Video output sockets available: • If so, you can continue with this procedure. • If not, you will need to reassess which method you can use to connect to the device. To connect the projector to a Component Video source device: 1.
Connecting an S-Video or a composite Video source device Examine your Video source device to determine if it has an unused S-Video or composite Video output socket available: • If so, you can continue with this procedure. • If not, you will need to reassess which method you can use to connect to the device.
5. Operation Start up 1. Plug the power cord into the projector and into a wall socket. Turn on the wall socket switch (where fitted). Check that the Power indicator on the projector lights orange after power has been applied. The power cable used in the illustration may look different to the power cable type used in your region. Use only the power cable as supplied with the projector, and which is suitable for your region. 2. Remove the lens cap.
If a PC input is selected and the resolution is not 800 x 600, you will see a Resolution Reminder as below. For a better picture quality, please change the PC’s resolution to 800 x 600 as requested. Resolution Reminder Analog RGB 1024 x 768 60Hz Dynamic In order to get better projection image quality, we suggest you to change your PC output resolution to SVGA (800 x 600).
iii. Press Down to cancel the password set-up and return to the OSD menu. To disable password protection, go to the the OSD menu system. Select Off by pressing Setting > Password menu after opening Left or Right. Though the password function is disabled, you need to keep the old password in hand should you ever need to turn the password function back on and change the old password.
Switching input signal The projector can be connected to multiple devices at the same time. However, it can only display one at a time. To cycle through the available input signals: 1. Press SOURCE on the projector or the remote control to display a source selection bar. If there has been a signal selected, press SOURCE twice. The first button press displays the current source information and the second displays the source selection bar. Source Selection D-Sub/Comp. Video S-Video 2.
To retract the foot, hold up the projector while pressing the quick-release button, then slowly lower the projector. Screw the rear adjuster foot in a reverse direction. If the screen and the projector are not perpendicular to each other, the projected picture becomes vertically trapezoidal. To correct this situation, adjust the value of Keystone in the Picture menu, on the projector control panel, or on the remote control. See "Correcting keystone" on page 25 for details.
Fine-tuning the picture clarity If needed, sharpen the picture by rotating the focus ring. If you are still not satisfied with the picture clarity, see "Sharpness" on page 35 to make further adjustment. Selecting the aspect ratio The 'aspect ratio' is the ratio of the picture width to the picture height. Most analog TV and computers are in 4:3 ratio, and digital TV and DVDs are usually in 16:9 ratio.
Optimizing the picture Selecting a picture mode The projector is preset with several predefined picture modes so that you can choose one to suit your operating environment and input source picture type. To select a picture mode that suits your need, you can follow one of the following steps. • Press MODE on the remote control or projector repeatedly until your desired mode is selected. • Go to the Picture > Picture Mode menu and press Left/ Right to select a desired mode.
Video input sources Video input sources are video (movie) based signal timings connected using the video cables Component Video (YPbPr), S-Video, or composite Video. Video input sources are active only when "YPbPr (Comp.)", "S-Video", or "Video" is selected as the input source. 1. 2. 3. Standard Mode (Default): Is appropriate for viewing colorful movies, video clips from digital cameras or DVs.
Adjusting Contrast The higher the value, the greater the contrast. Adjust this control so that white areas of the picture appear bright and that detail in the white areas remains visible. Use this after you have previously adjusted the Brightness setting to suit your selected input and viewing environment. -30 50 +70 Other adjustments You can find other picture quality fine-tune selections in the See "Picture menu" on page 35 for details. Picture menu as well.
4. 5. Press Down to highlight Timer Position and set the timer position by pressing Left/ Right. Upper left J lower left J upper right J lower right Press Down to highlight Timer Counting Direction and select your desired counting direction by pressing Left/ Right. Selection Count Up Count down 5 min 5 min 5 min 5 min Description Increases from 0 to the preset time. Decrease from the preset time to 0. 6. Press Up to highlight Timer Activate Confirm turning timer On? and press Left/ Right.
Freezing the picture Press on the remote control to freeze the picture. An icon will display in the lower right corner of the screen. To release the function, press on the remote control, or SOURCE on the projector. Note that pressing SOURCE will also change the input source. Even if a picture is frozen on the screen, the pictures are running on the video or other device.
Shutting down the projector 1. 2. Press Power and a prompt message appears. Press Power a second time to turn the projector off. The Power indicator light flashes orange and the lamp shuts down, the fans continue to run for approximately 110 seconds to cool down the projector. Are You Sure to Power Off? Press "Power" again to power off To protect the lamp, the projector will not respond to any commands during the cooling process. 32 3.
Menu operation Menu system Please note that the on-screen display (OSD) menus vary according to the signal type selected. Functions available when receiving different signal types...
Using the OSD menus The projector is equipped with on-screen display (OSD) menus for making various adjustments and settings. There are 17 different menu languages. (Refer to "Language" on page 38 for more details.) The following example describes the adjustment of Keystone. 1. Press MENU on the projector or MENU on the remote control to turn the OSD menu on. Picture Mode Dynamic Wall Color Off 4. Adjust keystone values by pressing Left/ Right on the projector or remote control.
Picture menu Some picture adjustments are available only when certain input sources are in use. Unavailable adjustments are not shown on the screen. FUNCTION (default setting / value) DESCRIPTION Picture Mode Pre-defined modes are provided so you can optimize your projector (PC: Dynamic; YPbPr/S-Video/ Video: Standard) Wall Color (Off) Color Temperature picture set-up to suit your program type. You can use the remote control MODE button to select a predefined Picture Mode.
Pro-Picture menu Some picture adjustments are available only when certain input sources are in use. Unavailable adjustments are not shown on the screen. FUNCTION (default setting/ value) DESCRIPTION Automatically resizes the input signal pixel resolution to the native resolution of the projector. Auto Resize (On) On: The pixel resolution of the input signal is converted to the native resolution of the projector (800 x 600).
Setting menu FUNCTION (default setting / value) DESCRIPTION OSD Time Sets the length of time the OSD will remain active after your last button press. The range is from 5 to 100 seconds. (20) Blank Timer (20) Sets the picture blank time when the Blank feature is activated, once elapsed the picture will return to the screen. This is a selectable function. Selecting On limits use of the projector to only those who know the correct password.
Advanced menu FUNCTION (default setting / value) Mirror ( ) Source Scan (On) DESCRIPTION (default setting / value) The projector can be installed on a ceiling or behind a screen, or with one or more mirrors. Contact your dealer for the ceiling mount bracket (optional accessory) if you need to install the projector on your ceiling. See "Choosing a location" on page 13 for details. Sets whether the projector searches automatically for input signals.
Information menu This menu shows you the current operating status of the projector. Some picture adjustments are available only when certain input sources are in use. Unavailable adjustments are not shown on the screen. FUNCTION DESCRIPTION Source Shows the current signal source. Resolution Shows the resolution of the input signal. System Shows the Video input system format, NTSC, SECAM or PAL. Picture Mode Shows the selected mode in the Equivalent Lamp Hour Picture menu.
6. Maintenance Care of the projector Your projector needs little maintenance. The only thing you need to do on a regular basis is to keep the lens clean. Never remove any parts of the projector except the lamp. Contact your dealer if other parts need replacing. Cleaning the lens Clean the lens whenever you notice dirt or dust on the surface. • • Use a canister of compressed air to remove dust.
Lamp information Calculation of lamp hour When the projector is in operation, the duration (in hours) of lamp usage is automatically calculated by the built-in timer. The method of calculating the equivalent lamp hour is as follows: Total (equivalent) lamp hour = 1 (hours used in Economic mode) + 3/2 (hours used in normal mode) See "Economic Mode" on page 38 for more information on Economic mode. The lamp hour in Economic mode is calculated as 2/3 of that in normal mode.
Lamp-usage time exceeded If this warning message displays, the projector will shut down in 40 seconds. The lamp MUST be replaced before the projector will operate normally. Replace lamp (refer to User Manual) Then reset lamp timer Replacing the lamp • To reduce the risk of electrical shock, always turn the projector off and disconnect the power cord before changing the lamp. • To reduce the risk of severe burns, allow the projector to cool for at least 45 minutes before replacing the lamp.
5. Disconnect the lamp connector by pushing it against the projector while pulling it up. 6. Loosen the screw that secures the lamp. 7. Lift the handle so that it stands up. Use the handle to slowly pull the lamp out of the projector. • Pulling it too quickly may cause the lamp to break and scatter broken glass in the projector. • Do not place the lamp in locations where water might splash on it, children can reach it, or near flammable materials.
12. Replace the lamp cover on the projector. 13. Tighten the screws that secure the lamp cover. • Loose screw may cause a bad connection, which could result in malfunction. • Do not over tighten the screws. 14. Restart the projector. Do not turn the power on with the lamp cover removed. 15. Resetting the lamp counter Do not reset if the lamp is not replaced as this could cause damage. i. Press and hold Up on the projector for 5 seconds to display the total used lamp time. ii.
Indicators Illustration • Blank -: Light OFF • : Light flashing • : Light ON Light • • O: Orange light R: Red light • G: Green light Status & Description Power Temp Lamp Power events O O O The projector has just been connected to a power outlet. O - - Stand-by mode. G - - Powering up. G - - Normal operation. 1. O - - O - - The projector needs 90 seconds to cool down as it was abnormally shut down without the normal cooling down process. Or 2.
Light Status & Description Power Temp Lamp Thermal events 46 - R - - R R - R G R O R R R R R G R R O G R R G R G G R O O R R O R G O R O - G R - G G Maintenance The projector has shutdown automatically. If you try to re-start the projector, it will shutdown again. Please contact your dealer for assistance. Downloaded From projector-manual.
7. Troubleshooting The projector does not turn on. Cause Remedy There is no power from the power cable. Plug the power cord into the AC inlet on the projector, and plug the power cord into the power outlet. If the power outlet has a switch, make sure that it is switched on. Attempting to turn the projector on again during the cooling process. Wait until the cooling down process has completed. No picture Cause Remedy The video source is not turned on or connected correctly.
8. Specifications Projector specifications All specifications are subject to change without notice. General Product name Model name Digital Projector MP510 Optical Resolution Display system Lens F/Number Lamp 800 x 600 SVGA 1-CHIP DMD F=2.57 (fixed) 160 W lamp Electrical Power supply Power consumption AC100–240V, 2.5A, 50–60 Hz (Automatic) 250 W (Max) Mechanical Weight 5.7 lbs (2.
Timing chart Supported timing for PC input Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Pixel Frequency (MHz) 31.469 37.861 37.500 43.269 31.469 37.879 48.077 46.875 53.674 48.363 56.476 60.023 68.667 63.981 59.940 72.809 75.000 85.008 70.087 60.317 72.188 75.000 85.061 60.004 70.069 75.029 84.997 60.020 25.175 31.500 31.500 36.000 28.322 40.000 50.000 49.500 56.250 65.000 75.000 78.750 94.500 108.
9. Warranty and Copyright information Limited warranty BenQ warrants this product against any defects in material and workmanship, under normal usage and storage. Proof of purchase date will be required with any warranty claim. In the event this product is found to be defective within the warranty period, BenQ's only obligation and your exclusive remedy shall be replacement of any defective parts (labor included).
10. Regulation statements FCC statement CLASS B: This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
