User Manual

SJ-PM-TFmini-T-01 A03
Benewake (Beijing) Co. Ltd.
Page6
1 Attentions
1.1 About this Document
 This manual provides all the essential information during the usage of this product.
 Please carefully read this manual and make sure that you fully understand everything herein.
1.2 Usage of Product
 The maintenance work of this product is limited to the professional technician, and the product
can only work with the factory spare part for ensuring the performance and safety thereof.
 This product itself has no polarity and over-voltage protection. Please properly connect and supply
power as per the manuals herein.
 Operating temperature of this product is between 0℃ and 60℃. Do not use it beyond this
temperature range to avoid risk.
 Storage temperature of this product is between -20℃ and 75℃. Do not store it beyond this
temperature range to avoid risk.
 For ensuring the product performance, do not open the product shell or do any assembly or
maintenance that not listed in this manual.
1.3 Conditions with Potential Product Failure
 The product will be subject to risk of failure if the detecting object has high reflectivity, such as
the mirror or the smooth floor tile.
 The product will be subject to risk of failure if there is any transparent object between it and the
detecting object, such as glass or water.
 The product will be subject to risk of failure if its transmitting or receiving len is covered by the
dust. Please keep the lens clean.
 Please do not directly touch circuit board of the product by hand as it is exposed. Please wear
antistatic wrist strap or glove if necessary; Otherwise, the product will be subject to risk of failure,
which is shown by failure of normal operation, and even it will be broken.
2 Functions and Key Parameters
2.1 Product Functions
TFmini is a mini LiDAR module. It is mainly capable of the function of real-time and contactless distance
measurement and is featured by accurate, stable and high-speed distance measurement.
