PROGRAM MESSAGES
The system program page (Figure 3-34) provides access to the mes-
sage page. When Message is selected on the system program page,
pressing the ENT key provides access to the AMD message sub-
pages. The sub-pages return to this page when the CLR key is
pushed to exit the page. There are four sub-pages below this selec-
tion:
Edit TX Edit/Review transmit messages.
Rev RX Review messages received.
Del RX Delete received messages.
Copy RX Copy a received message to a transmit
message.
The operator moves between these sub-pages by placing the cursor
on the sub-page field and turning the VAR knob to select another
sub-page.
EDIT TX (EDIT AMD TRANSMIT MESSAGES)
The transmit messages can be reviewed and edited on this page.
The VAR knob is used to select one of the AMD messages for modifi-
cation or review. To modify the AMD message the cursor is placed
on the second line, with the CRSR knob or the ENT key. Depressing
the VAR knob will change the field cursor to a character cursor and
the message can be entered or modified with the CRSR and VAR
knobs. The arrow on the second line indicates that there the mes-
sage is longer than the display width.
Operation
3-29
KHF 950/990 Pilots Guide
Rev. 0
Dec/96
SYS Program
}Messages
Figure 3-34 Sys Program Messages
