SEND PAGE
The selections available on the SEND page are: Transmit an AMD
message, perform a Link Quality Analysis (LQA), or perform a sound.
The transmit operation is based on the state of the radio before
selecting SEND mode. The following parameters must be setup
before entering the SEND page.:
• channel if not scanning
• ALE destination address for any AMD message.
SEND PAGE DISPLAYS
SSSSSSS * selection Message , SoundAs or LQA
## * message index Displayed only if ‘Message’
selected
line 2 * addr/msg ALE address or AMD message
* Cursorable fields.
SEND MESSAGE PAGE (TRANSMIT AMD MESSAGE)
The cursor can be placed over the message index or the AMD mes-
sage on line two. With the cursor placed on the AMD message field
the VAR knob can be used to select a pre-stored AMD (cursor in field
mode) or change the AMD message (cursor in character mode). The
transmit starts when the ENT key is pushed, or when microphone key
is activated. The Right arrow indicates that there is more data than
can fit on the screen. The display reverts to the ALE calling page
during the call. The address and channel used to transmit the mes-
sage depends on the current settings of the ALE page.
Operation
3-23
KHF 950/990 Pilots Guide
Rev. 0
Dec/96
SEND SSSSSSS ##
1234567890123456
Figure 3-24 Send Page Displays
