Specifications

OPTIONAL GAUGES CONTROLS AND DISPLAY
– 44 – Y53-6008A
Medium Duty (R05/09)
High Beam Headlamps
NOTE: The headlamps must be “ON” for the high
beam switch to operate.
• To switch your headlamps to lower or higher beam,
gently pull the turn signal lever towards the steering
wheel, until you hear the switch click and the beam
changes. The blue indicator light in the instrument
panel will be ON when the high beam is being used.
• To return to previous beam: pull the lever towards the
steering wheel again.
Headlamp Flash
To activate headlamp flash, gently push the turn signal
lever away from the steering wheel until you hear and feel
the switch click. Release lever to deactivate.
• If your headlamps are off, low beams will flash on.
• If your headlamps are on, they will dim. Maximum
duration of dimming is 3 seconds. When the function
ends, your headlamps will return to low beams.
ID And Clearance Lights Flash
To flash, press the button on the end of the turn signal
lever and hold. To cancel the flash, release the button.
If your ID and clearance lights are on, they will flash off.
Windshield Wipers/Washer
Your vehicle is equipped with a two-speed, intermittent
windshield wiper system. A seven-position rotary wiper
switch (located on the turn signal lever) operates the wind-
shield wipers and washer (see next illustration). Rotate
the end of the turn signal lever to change the wiper mode.
NOTE: The ignition key must be turned to ON or
ACC for the wiper/washer switches to operate.
Press Button For ID and Clearance Lights Flash
Press In For Washer Pump
Rotate To Change Wiper Mode
