Specifications

CONTROLS AND DISPLAYS INSTRUMENTS AND CONTROLS
Medium Duty
(R05/09) Y53-6008A – 29 –
40. Turn Signal, Right
Blinks when the right turn signal or the haz-
ard light function is operating.
41. Voltage
Illuminates when transmission lubricant tem-
perature is too high.The information display
will provide the current oil temperature when
the icon is illuminated.
Driver Information Display
WARNING! Do not look at the Driver Informa-
tion Display for prolonged periods while the
vehicle is moving. Only glance at the monitor
briefly while driving. Failure to do so can
result in the driver not being attentive to the
vehicle’s road position, which could lead to an
accident and possible personal injury or
equipment damage.
The Driver Information Display, located at the top of the
instrument cluster, displays important vehicle information
through a constant monitoring of systems when any of the
following conditions are met:
ignition key in ON or ACC positions
ignition timer is active
Voltage
12.6 Volts
