Specifications

CONTROLS AND DISPLAYS INSTRUMENTS AND CONTROLS
Medium Duty
(R05/09) Y53-6008A – 27 –
25. Lights, High Beam
Illuminates when the high beams are on.
This icon will flash with audible alarm if the
headlamps are left on when the door is open.
In addition, this icon will flash, but without an
audible alarm, if there is a problem with the
low beam headlights or the low beam head-
light wiring. In such event, the high beam
headlights will turn on at 50% normal bright-
ness.
26. Message Waiting
Illuminates with telematic equipped messag-
ing.
27. Park Brake
Illuminates in the status indicator when park-
ing brakes are applied and the vehicle is sta-
tionary. This symbol will also illuminate in the
Driver Information Display if the parking
brakes are applied and the vehicle is in
motion.
28.Power Take-off (PTO)
Illuminates when the PTO is engaged.
NOTE: Do not drive vehicle with PTO
engaged.
29.Power Take-off (PTO), Pump Mode
Illuminates with remote throttle application.
Indicates pump mode is active.
30. Refrigerator
Illuminates to indicate that the refrigerator is
on and ignition is off.
31. Seat Belt, Fasten
Illuminates when the ignition key is turned on
as a reminder to fasten your seat belt.
32.Suspension Dump
Illuminates when suspension air bags are
deflated.
