INSTRUMENTS AND CONTROLS CONTROLS AND DISPLAYS
– 22 – Y53-6008A
Medium Duty (R05/09)
Warning Light/Indicator Symbol Descriptions
1. Active Warnings, Exclamation Point
Illuminates when a red warning is active. Use
the MCS knob to view the warnings that are
active. Refer to the preceeding Figure , “Warning Light /
Indicator Symbols,” on page 20 for warning color classifi-
cation.
28. Power Take-off (PTO)
Green
27
29. Power Take-off (PTO),
Pump Mode
Green
27
30. Refrigerator
Green
27
31. Seat Belt, Fasten
Red
27
32. Suspension Dump
Yellow
27
33. Tire Inflation
Yellow
28
34. Transmission, Auxiliary
Yellow
28
35. Transmission, Check
Red
28
36. Transmission, Range
Inhibit
Red
28
Warning Light / Indicator Symbols
Symbol Name Symbol Color Std Opt Page
37. Transmission, Oil Filter
Yellow
28
38. Transmission, Oil Temper-
ature High
Yellow
28
39. Turn Signal, Left
Green
28
40. Turn Signal, Right
Green
29
41. Voltage
Orange
29
Warning Light / Indicator Symbols
Symbol Name Symbol Color Std Opt Page
