DEUTSCH
19
U-CONTROL UCA202
DIGITAL PROCESSING
Converter 16-bit converter
Sample rate 32.0 kHz, 44.1 kHz, 48.0 kHz
SYSTEM DATA
Frequency response 10 Hz to 20 kHz, ± 1 dB @ 44.1 kHz sample rate
10 Hz to 22 kHz, ± 1 dB @ 48.0 kHz sample rate
THD 0.05 % typ. @ -10 dBV, 1kHz
Crosstalk -77 dB @ 0 dBV, 1 kHz
Signal-to-noise ratio A/D 89 dB typ. @ 1 kHz, A-weighted
D/A 96 dB typ. @ 1 kHz, A-weighted
POWER SUPPLY
USB
connection 5 V , 100 mA max.
DIMENSIONS/WEIGHT
Dimensions (H x W x D) approx. 22 mm (0.87") x 88 mm (3.46") x 60 mm (2.36")
Weight approx. 0.12 kg
BEHRINGER always takes great care to ensure the highest standard of quality. Any modifications which may be
necessary will be made without prior notification. Technical data and appearance of the equipment can therefore differ
from the details or illustrations shown.
6. SPECIFICATIONS
