ULTRANET connector to daisy-chain
up to forty-eight P16-M mixers for
large systems (in conjunction
with P16-D)
Ultra-low system latency of less than
1 millisecond
Powered via external power supply
(included) or P16-I / P16-D
Mounts easily on a mic stand with the
P16-MB mic stand mount
(not included)
P16-I — 16-Channel 19" Input
Module with Analog and ADAT
Optical Inputs
Converts 16 analog inputs into 24-bit
digital audio to be transmitted via
standard CAT5e cable
2 x 8-channel ADAT optical inputs
with auto detect and priority select
16 balanced, high-headroom
TRS audio inputs
State-of-the-art 24-bit A/D converters
for premium audio quality
4-position gain switches per channel
pair (-10, 0, +4, +22 dB)
Digital inputs support 44.1 and
48 kHz sample rates
Ultra-low system latency of less
than 1 millisecond
Signal Present and Clip LEDs per
channel plus ADAT status LEDs
Standard CAT5e connection
delivers power and signals for up to
6 Personal Mixers
ULTRANET expansion network
connector (RJ45)
Easy Installation
A basic installation consists of one
P16-I audio interface, which connects to
the main mixing console, and up to six
P16-M Personal Mixers, creating a system
big enough to equip a typical recording
studio, a small to medium-sized band,
or a worship team. You’ll also need a
few standard audio and CAT5 cables.
The optional P16- MB mounting bracket
allows the P16-M Digital Personal Mixer to
be attached to any standard microphone,
music or drum stand. The system can
easily be expanded via the P16-D Digital
ULTRANET Distributor, six of which can be
combined to drive up to forty-eight P16-M
Personal Mixers.
Extraordinary Value
The POWERPLAY P16 puts total control
of the monitor system where it belongs—
in the hands of the performers, freeing up
the engineer to sculpt the perfect front-of-
house mix. The POWERPLAY P16 system is
the easy, a ordable way to tame runaway
stage volume and give your musicians
and vocalists what they really want—
“more me!”
