Specification Sheet

3
Energy-Efficient, 9-Input Mixer Featuring Multiple Input Connectivity and Diverse Signal Routing
MA4000M
Audio Inputs
Mic / Line inputs 1 & 2
• Type 2 x XLR / ¼" TRS combo jacks
2 x 4-pin Euroblock in parallel
• Impedance Mic: -50 to 0 dBV, 600 Ω
Line: -27 to 0 dBV, 600 Ω
Electronically balanced
Mic / Line inputs 3 & 4
• Type 2 x XLR / ¼" TRS combo jacks
2 x 3-pin Euroblock in parallel
• Impedance Mic: -50 to 0 dBV, 600 Ω
Line: -27 to 0 dBV, 600 Ω
Electronically balanced
Inputs 5 - 8
• Type 4 x 3-pin Euroblock,
electronically balanced
• Impedance Mic: -50 to 0 dBV, 600 Ω
Line: -27 to 0 dBV, 600 Ω
Auxiliary
• Type 4 x RCA stereo summed
• Impedance Line: -10 dBV, 10 kΩ, unbalanced
Tel / Page input 1 x 4-pin Euroblock
• Impedance Mic: -50 to 0 dBV, 600 Ω
Line: -27 to 0 dBV, 600 Ω
Phantom power 24 VDC, switchable
Inputs 1– 8 and Tel / Page
Audio Outputs
Main mix outputs 1 & 2 2 x 3-pin male Euroblock,
Mic/Line switchable
• Impedance Mic: -40 dBV, 1 kΩ
Line: 0 dBV, 600 Ω
Electronically balanced
Z2 / Mon output 1 x dual RCA jack
• Impedance 0 dBV, 600 Ω, unbalanced
Record output 1 x dual RCA jack
• Impedance 0 dBV, 600 Ω, unbalanced
System Information
• Dynamic range Mic: 65 dB
Line: 80 dB
• THD+N 0.5% @ 1 kHz, rated output
• Frequency response 50 Hz - 18 kHz, ±2 dB
• Tone controls Low: ±12 dB @ 100 Hz
High: ±12 dB @ 10 kHz
Control Connections
• Remote 1 x 5-pin Euroblock connector
• Volume 10 kΩ linear-taper potentiometer
• Power +5 VDC voltage make contact
input; no open voltage
• Mute No-voltage make contact input;
open voltage 5 VDC
Short circuit: < 10 mA
• DC power +5 VDC, 100 mA Current limited,
short-circuit protected
Tel / Page 1 x 4-pin Euroblock, 1 terminal
• Mute No-voltage make contact input;
open voltage 24 VDC
Short circuit: < 10 mA
Inputs 1 & 2 2 x 4-pin Euroblock, 1 terminal each
• Mute No-voltage make contact input;
open voltage 24 VDC
Short circuit: < 10 mA
Indicators
• Power LED ring illumination (Yellow)
• Overload / protection LED ring indication (Red)
• Output level LED VU output meter
(Yellow and Red while clipping)
Power Supply (Fuses)
• Mains voltage 100-240 VAC, 60/50 Hz
• Fuse T 1 AH 250 V
• Power consumption 26 W
• Mains connector Standard IEC receptacle
Dimensions / Weight
• Dimensions (H x W x D) 3.5 x 17 x 16" / 88 x 432 x 406 mm
• Weight 10.2 lbs / 4.6 kg
Technical Specications
