Specification Sheet

2
Energy-Efficient, 9-Input Mixer Featuring Multiple Input Connectivity and Diverse Signal Routing
MA4000M
Product Overview
TheEUROCOMMA4000Mprofessionalmixer
oersextraordinaryexibilityandease-of-useina
rack-mountablesystemthatisidealforcommercial
installationapplicationssuchasrestaurants,bars,
stores,sportsclubs,spas,andhousesofworship.
Designedforeasyoperationbynon-technicalpersonnel,
theMA4000Mcombinesaclear,intuitivefrontpanelwith
back-panelcontrolsthatallowtheinstallertremendous
exibilityincustomizingthemixertotheneedsofeach
individualinstallation.
TheMA4000Mincludeseightsource-switchablechannels
forbalancedorunbalancedinputfromline-levelsources
ormicrophones,eitherstandardorphantompowered.
AllchannelsacceptinputviaEuroblockconnectors
(six3-pinandtwo4-pinwithmuteterminals)andhave
bothasignalLEDandaleveltrim.Inputs1-4alsohave
XLR/TRS(¼-inch)combinationjacks,whileinputs5-8
eachhaveapairofRCAjacks,summedinternallyto
mono,forsourcessuchasCD/MP3players,cableboxes,
andradio/TVtuners.A4-pinEuroblockconnector
providesanadditionalinputfortelephonepaging,anda
5-pinEuroblockallowsconnectionofaremotecontrol.
Outputs,allmono,includetwomainmixoutson3-pin
Euroblocksandtwofeedsthatareeachsplittoapairof
RCAjacks,onearecordingfeed(pre-mastermainmix)
andoneaZone2/MusiconHoldmixthatmaybeused
tofeedasupplementalsoundreinforcementsystem.
TheZ2/MOHmixincludesonlyinputchannelsassigned
viaback-panelZ2/MOHDIPswitches.DIPswitchesalso
determinewhetherthemainmixoutsarelineormiclevel,
enableinputs5-8inthemainmix,andselectthepaging
input.TrimpotsareprovidedtoadjusttheZone2/MOH
outputlevel,thepaginginputlevel,andmutedepth,
whichdeterminesthedegreeofattenuationduring
automaticduckingofbackgroundaudio.
Front-panelcontrolsincluderotaryfadersforinputlevels
aswellashighandlowEQtooptimizethesoundfor
anyenvironment.Thefront-panelmastervolumeknob
issurroundedbyanindicatorringthatglowsyellow
whentheunitispoweredandashesredattheonset
ofclipping.AVUmeterisprovidedtoindicateoutput
signallevel.
Combiningexceptionallyexiblesignalroutingwith
allkeyfunctionsforrack-mountedmixingandpaging,
theMA4000Misatonceremarkablyversatileandeasy
touse,makingitanoutstandingvalueforawidevariety
ofcommercialinstallationsinhospitality,retail,leisure,
andbusinesssettings.
