Owner's Manual

6 DIGITAL MONITOR SPEAKERS MS40/MS20 User Manual User Manual
Begin by connecting the left speaker to the right speaker by wiring the attached
speaker cable from connector (14) to connector (16) on the left speaker.
Connect the analog outputs of your mixer, keyboard or computer sound card to
LINE 1 input (12). Connect a second piece of equipment to LINE 2 inputs (13).
If you own equipment with digital connectors—such as CD or MD players—
simply connect them to the digital inputs (8) and (9). Select the digital signal
you want to monitor with the input selector switch (10).
You can mix two input signals within the MS20/MS40 by using the volume
controls (6) and (7). This enables you to monitor two dierent sound sources
simultaneously. The above wiring example shows how you can monitor your live
keyboard performance to a playback coming from your MD player or digital audio
workstation (computer).
The MS20/MS40 speakers are shielded, which allows you to place them near your
computer monitor without causing interference or damage. However, do not
place your MS20/MS40 speakers near power amps. Doing so will result in an
induced hum in your speakers.
4. Specications
Loudspeakers
MS40
Tweeter Ø 65 mm (2 ½"), 8 Ω
Woofer Ø 120 mm (4 ¾"), 4 Ω
MS20
Tweeter Ø 65 mm (2 ½"), 8 Ω
Woofer Ø 92 mm (3 ⁄"), 4 Ω
Audio Inputs
Line 1 ⁄" TRS stereo, impedance 20 kΩ
Line 2 2 RCA, impedance 20 kΩ
Digital Inputs
Optical TOSLINK
Coaxial RCA
Converter 24-bit
Sample rate < 192 kHz
System Specications
MS40
Output power 2 x 20 W
Frequency response 50 Hz to 25 kHz
MS20
Output power 2 x 10 W
Frequency response 65 Hz to 25 kHz
Power Supply
Mains Voltages
USA/Canada 120 V~, 60 Hz
Europe/U.K./Australia 230 V~, 50 Hz
China 220 V~, 50 Hz
Japan 100 V~, 50 - 60 Hz
General export model 120/230 V~, 50 - 60 Hz
Power consumption
MS40: 90 W
MS20: 80 W
Physical
MS40
Dimensions (H x W x D) 11 x 6 ⁄ x 9 ⁄"
279 x 173 x 245 mm
Weight right: 10.78 lbs / 4.9 kg
left: 7.04 lbs / 3.2 kg
MS20
Dimensions (H x W x D) 9 ⁄ x 6 x 7 ⁄"
239 x 154 x 187 mm
Weight right: 8.14 lbs / 3.7 kg
left: 4.51 lbs / 2.05 kg
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts,
modifications may be made from time to time to existing products without prior notice. Specifications and
appearance may differ from those listed or illustrated.
