8188RF Wireless Smart Office Keyboard & Mouse Kit User’s Guide Version 1.
The information in this document is subject to change without notice and does not represent a commitment on the part of the vendor. No warranty of representation, either expressed or implied, is made with respect to the quality, accuracy or fitness for any particular purpose of this document. The manufacturer reserves the right to make changes to the content of this document and/or the products associated with it at any time without obligation to notify any person or organisation of such changes.
Table of Contents 1 Introduction.................................................................................................1 What's in this package ..............................................................................1 2 System Requirements ................................................................................3 3 Hardware Installation ................................................................................4 4 Software Installation .....................................
1 Introduction Congratulations on your purchase of the wireless USB smart Office keyboard and mouse kit! This keyboard and mouse kit will finally free you of the constraints of your desktop by providing a wireless connection between the keyboard or mouse and your PC.
2 A driver disc Batteries (4pcs of AA alkaline batteries)
2 System Requirements Microsoft Windows 98, Windows ME, Windows 2000 or Windows XP operating system Microsoft Internet Explorer 5.
3 Hardware Installation Slide Switch Setting Step 1: Make sure your PC is switched off. Step 2: Take the receiver and select channel CH1 or CH2 by using the slide switch on the back of the receiver. (Remember your selection.) Bottom View of Slide Switch Setting of Receiver Step 3: Connect the receiver to your PC by plugging in the receiver’s USB connector into your PC. USB Connector Step 4: Take the keyboard and make sure the batteries on the back are installed correctly.
Channel Switch ID Button Bottom View of 5
Step 5: Use the slide switch on the back of the keyboard to select the same channel as the one selected in step 2 on the receiver. Slide Switch Setting Step 6: Take the mouse and make sure the batteries on the back are installed correctly. (Follow the polarity signs in the battery compartment.) ID Button Synch Button Bottom View of Channel Switch Step 7: Use the slide switch in the battery compartment of the mouse to select the same channel as the one selected in step 2 and 5.
ID Setting This keyboard kits contains 2 channels and each channel contains 256 sets ID. This extra ID-recognition function helps to protect against interference from other RF keyboards in the same environment. After completing the hardware installation you must set the ID’s of the receiver, mouse and keyboard. Step 1: Press the ID button on the top of the receiver once.
Remarks: 1. You must follow the procedure above to set the ID of receiver, mouse and keyboard. Once the receiver ID button is pressed you have 35 seconds to complete the entire process, or you will need to begin again. 2. Once the keyboard and mouse USB connectors are plugged in the yellow receiver light will flash. Once the ID is set, it will remain steadily lit. 3. When changing the batteries of keyboard there is no need to reset all the ID’s. Simply reset one of them. 4.
4 Software Installation After completing the hardware installation and turning the PC power on you will have immediate access to the alpha-numeric keys of the keyboard. In order to utilize the specialty keys you must first install the keyboard driver using the CD included in the box. To install the keyboard driver: Step 1 : Remove any existing keyboard software from the computer. Step 2: Insert the driver CD in your computers CD-ROM drive, the software will auto run.
5 Uninstallation Please note that you have to uninstall the driver first if you want to reinstall the driver. To uninstall the keyboard driver: and select "Exit" command to exit Step 1: Right-click the driver icon the driver program. Step 2: Click "Start" menu (on the left-bottom taskbar). Step 3: Move cursor to "Programs" in "Start" menu. Step 4: Move cursor again to "KeyMaestro". Step 5: Select "Uninstallation". Step 6: Click on the “Remove Program” icon.
6 Smart Office Keyboard Driver 6.1 To Pop Up “KeyMaestro” Dialogue Box Use left-click of the mouse on the Smart Office Keyboard Driver ico on the taskbar, a “KeyMaestro” dialogue box will pop up with the following functions. 6.1.1 Select a HotKey This function contains the default function of a key. You can click on the "Display Label" box to re-define the key functions. Please refer to the “Configure Button” dialogue below. 6.1.
Auto play function. The default of this function is enabled.
6.2 To Pop Up “Configure Button” Dialogue Box 6.2.1 Label In the Label box, type the name of application that the button will launch, or any name that will help you remember the function of the button. This label will appear on screen each time you press the button. 6.2.2 Functions You can see a list of predefined functions and set one of it for the button. 6.2.3 Launch Application or Website Type in the path to an often used application or click the Browse button to select any file on your computer.
how to solve your problem.
7 Using the Keyboard 7.1 Office Application Keys Block Word Open Microsoft Word. Excel Open Microsoft Excel. PowerPoint Open Microsoft PowerPoint. Calendar Open “Calendar” function of Microsoft Outlook. 7.2 Internet Keys Block 7.3 Back Return to the last page you viewed. Forward View the next page you viewed before. Stop If a page you are trying to view is taking too long to open, click this button to stop.
Note: If “Log Off” key function cannot work properly, see “Troubleshooting” for more information.
7.4 Multimedia Keys Block Mute Mute the sound. Volume up Adjust the volume up. Volume down Adjust the volume down. Stop Stop the playing. Previous Skip backward to the previous file/track when pressing once. Next Skip forward to the next file/track when pressing once. Play/Pause When the CD or Video is playing, press this button to pause it, and press the button again to resume it from the current position. 7.
F3: Open Open or finds a file in program. F4: Save save the active file with current file name, location and file format. F5: Replace Search for and replaces the specified text and formatting. F6: Spell Start the spelling check program in the active document. F7: Undo Reverse the last command or deletes the last entry you typed or action. F8: Redo Reverse the action of the Undo command. F9: Reply Reply to the e-mail in Microsoft Outlook or Outlook Express.
functions of embedded office keys. So, some enhanced functions are only for target language usage. The descriptions of the enhanced office keys’ functions are for reference and may not reflect your keyboard exactly.
7.
1. Works as a mouse with scrolling functions in 2 directions - up and down. You can use the up and down functions of the Scroll Wheel to scroll the document horizontally. Scroll Wheel 2. Works as a mouse button. When you push on the scroll wheel, a series functions dialogue will pop-up as below. Their functions are divided into 3 parts. Works as “Internet keys” or “Multimedia keys”. You can customize the push button as one of these functions.
22 Cut Remove the selection from the active document. Copy Copy the selection to the Clipboard. Paste Paste the previously cut or copied items from the Clipboard. Mark Press on the mark key once and use the up, down, right and left direction keys to select items. Press the mark key again or any other keys except the up, down, right, left, home, end, page up or page down key, the mark function can be released. APP.
8 Using the Mouse 8.1 Using the Mouse Driver After installing the mouse driver as described in Chapter 4 you will be able to start up the Mouse Control Panel by left double-clicking on the KeyMaestro Mouse icon in the Windows task bar. This should appear after restarting your machine. You can also invoke the Mouse Control Panel by choosing Start→Programs→MMaestro →KeyMaestro Mouse Driver.
24 Orientation folder: allows you to setup the angle of the mouse when moving upwards.
8.2 The Definition of Mouse Extra Function: Function Definition Quick Jump Let you to open 8 special functions quickly. For the detailed, please refer to the ”Quick Jump Function Introduction” in next section. Double Click Replace the "double click" movement to activate an application or function, it can save the valuable mouseclicks. To magnify or de-magnify the data view of a document in an application that supports it.
8.3 Quick Jump Function Introduction Also, after installing the mouse driver and invoking the KeyMaestro mouse driver program you will have access to 9 special function icons by pressing the scroll wheel once. These 9 functions are: Mouse Control PanelActivate the Mouse Control Panel Menu. Control Panel Activate the “Control Panel” window. Set the cursor to the horizontal scroll bar to Horizontal Scroll Bar scroll the document horizontally.
and select Help.
9 Troubleshooting If you are experiencing problems with your keyboard, please check the following: 1. Keyboard & Mouse do not work properly Please re member to set the ID when your keyboard kits do not work properly. 2. Mouse does not work accurately Use the mouse only on a clean, flat, non-slippery surface in order to ensure smooth and accurate cursor action. If you use a mouse-pad, choose a light-colored one, not a dark one, to use less battery power. 3.
7. Word, Excel, PowerPoint, Calendar cannot do action, but the onscreen can show up Please make sure you have installed the Office Applications completely. If Office Applications are not fully installed, those keys can only see the onscreen display and do not work. 8. Sleep key does not work properly If you have problems using the sleep button, make sure that the power management in your PC has been enabled both in the BIOS and in Windows.
replace Office 97, or use IE 5.0 to replace IE 4.0.
Technical Support If the above instructions do not solve your problem, please contact Memorex technical support at techsupport@memorex.com, or visit us online at www.memorex.com for our Frequently Asked Questions (FAQ). Memorex Products One Year Limited Warranty. Memorex Products, Inc. will replace this product free of charge if it is found to be defective in materials or workmanship during normal usage conditions for a period of one year from date of purchase (proof of purchase required).
封底內頁 FCC GUIDELINES This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions may cause harmful interference to radio communications.
