BBZ301 BLUETOOTH CONTROLLED HELICOPTER USER GUIDE
For additional informations, visit our website www.bee-wi.
User’s guide ENGLISH FRANCAIS DEUTSCH ITALIANO ESPAñOL PORTUGUES NEDERLANDS Български Român 4 12 20 28 36 44 52 60 68
Thank you for purchasing the BBZ301 Bluetooth RC Helicopter from BEEWI. Please read the following instructions to learn how to configure and use more effectively your product. INTRODUCTION The BBZ301 Bluetooth RC Helicopter can be controlled directly from your Smartphone using the specific BeeWi HeliPad application available on Android Market. The Bluetooth RC Helicopter works as a regular RC Helicopter with throttle, left/right and forward/backward directions.
- 2 control modes: normal and expert 1.3. Product Outlook 1: Main blades (2) 2: Tail blade 3: Stabilizer 4: Front Light 1.4. Product Specifications BLUETOOTH CHIP Bluetooth 3.0 BLUETOOTH RANGE Class 2, 10 m typical, up to 20 m PROTOCOL SPP Serial Profile BATTERY Lithium Polymer 180 mAH TYPICAL USE TIME Up to 8 minutes continuous CHARGE TIME Up to 40 minutes SERVO CONTROLS 3 channels + gyroscope DIMENSIONS L 200 mm x H100 mm x W40 mm WEIGHT 45 g 2. Initial SETTINGS 2.1.
charging socket located underneath the helicopter. Do not force, the cable end should connect smoothly. - During the charging process, the USB charger light will turn off; if the light turns on again, it means the helicopter is fully charged. 2.2. BeeWi HeliPad Installation Go to Market and look for “BeeWi-HeliPad” app. Follow the on-screen indications to download and install the app. Once the application has been successfully installed, you can launch it directly.
Note: you can also pair the Helicopter directly in the app by opening the “Select Helicopter” Menu and searching the Helicopter. In that case, select the device name “BeeWi BBZ301” on the screen and enter the pass key “0000” to add this device into your phone device list 3. Using the Helicopter 3.1. Connection Open the BeeWi HeliPad application and display the application menu using the mobile Menu key then press “Select Helicopter” to see the list of paired devices.
3.2. Operation When the Helicopter is connected, you can access the control screen below. By default the control is motion and the trimmer is set to “0”. 1: Throttle 2: Direction stick 3: Trimmer 4: Flying mode 5: Touch/Motion control Gently push the throttle until the Helicopter engine turns on.
When you feel confident with the direction commands, you can start to fly your Helicopter. Softly push the throttle until your Helicopter is taking off. Try to maintain it at a steady height using the throttle before using the direction commands. Once you are confident with the throttle control, you can state to use all commands and train yourself with the following circuits. 3.3. Configuration The configuration menu can be accessed by opening the Menu bar using the phone Menu key.
4. Cautions & Maintenance Warning: - Please read carefully the complete manual before flying and strictly follow the instructions given. - This product is not suitable for children under 14 years old. - This product is not suitable for small children – risks of small parts breaking off and potential choking hazard. - Stay away from the product when it is turned on. Do not come closer or touch the rotating parts. - Do not disassemble or rework the product as this may cause damage and void the warranty.
European Union Directives Conformance Statement Hereby, VOXLAND declares that this product is in compliance with: • The essential requirements and other relevant provisions of Directive 1999/5/EC • All other relevant EU Directives You can view your product’s Declaration of Conformity (DoC) to Directive 1999/5/EC (to R&TTE Directive) at www.bee-wi.com. Federal Communications Commission This device complies with Part 15 of the FCC rules and with RSS-210 of Industry Canada.
Merci d’avoir choisi l’hélicoptère télécommandé Bluetooth BBZ301 de BEEWI. Veuillez lire les instructions suivantes afin de configurer et utiliser au mieux votre appareil. INTRODUCTION L’hélicoptère télécommandé BBZ301 peut être contrôlé directement par votre Smartphone en utilisant l’application spécifique BeeWi HeliPad disponible sur Android Market. L’hélicoptère Bluetooth fonctionne comme un hélicoptère télécommandé conventionnel avec commandes de gaz et directions avant/arrière et gauche/droite.
- Application BeeWi HeliPad compatible avec les appareils Android, version 2.1 et plus - Commandes intuitive utilisant le capteur d’orientation et l’interface tactile du mobile - 2 modes de contrôle : normal et expert 1.3. Présentation du produit 1. Palles (2) 2. Hélice arrière 3. Balancier 4. Lumière frontale 1.4. Spécification Technologie Bluetooth 3.
pas forcer, la connexion se fait en douceur. - Durant la charge, l’indicateur lumineux s’éteint ; s’il s’allume à nouveau, cela signifie que la batterie est chargée. 2.2. Installation de l’application BeeWi HeliPad Aller sur Market et rechercher l’application « BeeWi HeliPad ». Suivre les indications pour télécharger et installer l’application. Une fois l’application installée, vous pouvez la lancer directement.
Note: il est possible d’appairer l’hélicoptère directement dans l’application en ouvrant le menu “Choisir Hélicoptère” et en recherchant l’hélicoptère. Dans ce cas, sélectionner l’appareil ‘BeeWi BBZ301’ sur l’écran et entrer le code ‘0000’ pour ajouter cet appareil à la liste d’appairage. 3. Utilisation de l’hélicoptère 3.1.
3.2. Utilisation Lorsque l’hélicoptère est connecté, l’écran de contrôles est accessible. Par défaut le contrôle est effectué en utilisant le capteur de mouvement et le réglage de direction (trimmer) est à zéro. 1. Manette des gaz 2. Levier de direction 3. Trimmer 4. Mode de pilotage 5. Contrôle Tactile/ Mouvement Pousser doucement les gaz jusqu’à ce que l’hélicoptère se mette en marche.
Une fois les commandes de direction acquises, vous pouvez faire voler votre hélicoptère. Pousser doucement la commande de gaz jusqu’à ce que l’hélicoptère s’envole et essayer de le maintenir à une altitude stable. Une fois la commande de gaz bien maitrisée, vous pouvez commencer à utiliser l’ensemble des commandes et vous entrainer à suivre les circuits suivants. 3.3. Configuration Le menu de configuration est accessible par la touche Menu du mobile.
4. Maintenance et précautions d’usage Attention: - Merci de lire attentivement le manuel complet et de suivre strictement les instructions qui vous sont données avant le vol. - Ce produit n’est pas destiné aux enfants de moins de 14 ans. - Ce produit ne convient pas aux enfants en bas âge – risques de casse et d’étouffement par ingestion de petites pièces. - Garder ses distances lorsque le produit est en marche. Ne pas s’approcher trop près ou toucher les parties en rotation.
Déclaration de conformité aux directives de l’Union Européenne VOXLAND déclare que ce produit est en conformité avec : • Les dispositions essentielles ainsi que toutes provisions afférentes de la directive 1999/5/EC • Toutes autres Directives de l’Union Européenne afférentes Vous pouvez visualiser la Déclaration de Conformité (DoC) à la directive 1999/5/EC (à la Directive R&TTE) sur le site www.bee-wi.com.
Wir danken Ihnen für Ihre Wahl des ferngesteuerten Hubschraubers Bluetooth BBZ301 von BEEWI. Bitte lesen Sie sich die folgenden Anweisungen durch, um Ihr Gerät so gut wie möglich zu konfigurieren und zu benutzen. Einleitung Der ferngesteuerte Hubschrauber BBZ301 kann direkt über Ihr Smartphone gesteuert werden, indem Sie die spezifische Anwendung BeeWi HeliPad verwenden, welche auf Android Market zur Verfügung steht.
- Aufladung USB Standard - BeeWi HeliPad Anwendung kompatibel mit den Android Geräten Version 2.1 und mehr - Intuitive Bedienung mithilfe es Orientierungssensors und des TouchInterfaces des Mobiltelefons - 2 Steuermodi: Normal und Experte 1.3. Produktvorstellung 1. Blätter (2) 2. Hinterer Propeller 3. Ausleger 4. Vordere Leuchte 1.4. Spezifikation Technologie Bluetooth 3.
Kabels in den Anschluss unter dem Hubschrauber. Wenden Sie keine Gewat an, der Anschluss erfolgt behutsam. - Während des Ladevorgangs erlischt die Leuchtanzeige; wenn sie wieder angeht, bedeutet dies, dass die Batterie aufgeladen ist. 2.2. Installation der BeeWi HeliPad Anwendung Begeben Sie sich auf Market und suchen Sie die Anwendung "BeeWi HeliPad". Befolgen Sie die Anweisungen für das Herunterladen und installieren Sie die Anwendung.
Anmerkung: es ist möglich, den Hubschrauber direkt in der Anwendung zu pairen, indem Sie das Menü 'Select helicopter’ öffnen und den Hubschrauber suchen. Wählen Sie in diesem Fall das Gerät 'BeeWi BBZ301’ auf dem Bildschirm aus und geben Sie den Code '0000’ ein, um dieses Gerät der Pairing-Liste hinzuzufügen. 3. Benutzung des Hubschraubers 3.1.
3.2. Benutzung Wenn der Hubschrauber angeschlossen ist, ist der Steuermonitor zugänglich. Standardmäßig erfolgt die Steuerung durch die Benutzung des Bewegungssensors und die Richtungseinstellung (Trimmer) steht auf Null. 1. Gashebel 2. Lenkhebel 3. Trimmer 4. Steuermodus 5. Touch-/BewegungsSteuerung Betätigen Sie behutsam den Gashebel, bis dass der Hubschrauber sich in Bewegung setzt.
Sobald die Steuerung beherrscht wird, können Sie Ihren Hubschrauber fliegen lassen. Drücken Sie behutsam den Gashebel, bis dass der Hubschrauber abhebt und versuchen Sie, ihn in einer stabilen Höhe zu halten. Sobald Sie den Gashebel beherrschen, können Sie beginnen, alle Steuerungen zu benutzen und üben, folgende Strecken zu fliegen. 3.3. Konfigurierung Das Konfigurationsmenü ist über die Menü-Taste des Mobiltelefons zugänglich.
4. Pflege und Vorsichtshinweise für die Verwendung Achtung: - Lesen Sie sich bitte vor der Benutzung sorgfältig das komplette Handbuch durch und beachten Sie bitte genau die Anweisungen, die Ihnen gegeben werden. - Dieses Produkt ist nicht für Kinder unter 14 Jahren bestimmt. - Dieses Produkt ist nicht für Kleinkinder geeignet – Bruch- und Erstickungsrisiko durch verschluckte Kleinteile. - Halten Sie Abstand, wenn das Gerät in Betrieb ist.
Erklärung der Konformität mit den Richtlinien der Europäischen Unione Hiermit erklärt VOXLAND, das dieses Produkt folgende Bestimmungen erfüllt: • Die wichtigsten Bestimmungen und andere relevante Regelungen der Richtlinie 1999/5/EU • Alle anderen relevanten EU-Richtlinien Die Konformitätserklärung des Produkts mit der Richtlinie 1999/5/EU (in Bezug auf die R&TTE Richtlinie) kann auf unserer Website eingesehen werden: www.bee-wi.
Grazie per aver scelto l'elicottero telecomandato tramite Bluetooth BBZ301 di BEEWI. Leggere attentamente le seguenti istruzioni per configurare e utilizzare al meglio il proprio elicottero. Introduzione L'elicottero BBZ301 può essere telecomandato direttamente tramite smartphone, utilizzando la specifica applicazione BeeWi HeliPad disponibile su Android Market.
- Applicazione BeeWi HeliPad compatibile con i dispositivi Android, versione 2.1 e superiori - Comandi intuitivi che utilizzano il sensore di orientamento e l'interfaccia touch screen del dispositivo mobile - 2 modalità di controllo: Normal ed Expert 1.3. Presentazione del prodotto 1. Pale (2) 2. Elica posteriore 3. Bilanciere 4. Luce frontale 1.4. Specifiche Tecnologia Bluetooth 3.
si spegne. Quando la batteria è completamente carica, l'indicatore si accende nuovamente. 2.2. Installazione dell'applicazione BeeWi HeliPad Andare su Market e cercare l'applicazione "BeeWi HeliPad". Seguire le istruzioni per scaricare e installare l'applicazione. Una volta installata l'applicazione, avviarla direttamente. Prima di utilizzare l'elicottero, verificare che sia stato abbinato e connesso al dispositivo mobile. 2.3.
l'elicottero. In questo caso, selezionare il dispositivo ‘BeeWi BBZ301’ sullo schermo e inserire il codice ‘0000’ per aggiungere questo dispositivo all'elenco di pairing. 3. Utilizzo dell'elicottero 3.1. Connessione Aprire l'applicazione BeeWi HeliPad e visualizzare i menu premendo il tasto Menu del dispositivo mobile, poi attivare il menu ‘Select Helicopter' per visualizzare i dispositivi abbinati. 1 2 1 2 Verificare che l'elicottero sia acceso e selezionarlo nell'elenco.
il sensore di movimento e con la regolazione di direzione (TRIMMER) impostata su zero. 1. Manetta del gas 2. Leva di direzione 3. Trimmer 4. Modalità di pilotaggio 5. Controllo Touch/ Motion Premere delicatamente il comando del gas, fino a che l'elicottero si mette in movimento.
Dopo aver imparato a utilizzare i comandi direzionali, è possibile far volare l'elicottero. Premere delicatamente il comando del gas fino a che l'elicottero si alza in volo e provare a mantenerlo a un'altezza stabile. Dopo aver imparato a utilizzare correttamente il comando del gas, iniziare a utilizzare gli altri comandi ed esercitarsi nel seguire i seguenti circuiti. 3.3. Configurazione Il menu di configurazione è accessibile premendo il tasto Menu del dispositivo mobile.
4. Manutenzione e precauzioni d'uso Attenzione: - Prima del volo, leggere con attenzione l'intero manuale e seguire le istruzioni in modo rigoroso. - Questo prodotto non è destinato all'uso da parte di bambini di età inferiore ai 14 anni. - Questo prodotto non è adatto a bambini piccoli a causa del rischio di rottura e di conseguente soffocamento per l'ingestione dei pezzi più piccoli. - Mantenere le distanze di sicurezza quando il prodotto è in movimento.
Direttive dell’Unione europea sulla dichiarazione di conformità Con la presente, VOXLAND dichiara che questo prodotto è conforme con: • I requisiti essenziali e le altre disposizioni rilevanti di cui alla Direttiva 1999/5/EC • Tutte le altre Direttive UE rilevanti La nostra dichiarazione di conformità (DoC: Declaration of Conformity) alla Direttiva 1999/5/EC (Direttiva R&TTE) può essere visualizzata sul sito www.bee-wi.com.
Gracias por elegir el helicóptero teledirigido por Bluetooth BBZ301 de BEEWI. Lea las instrucciones siguientes que le ayudarán a configurar y utilizar mejor su dispositivo. Introducción El helicóptero teledirigido BBZ301 se puede controlar directamente a través de su smartphone utilizando la aplicación específica BeeWi HeliPad disponible en Android Market. El helicóptero Bluetooth funciona como un helicóptero convencional con mandos de gas y direcciones adelante/atrás e izquierda/derecha.
- Carga USB estándar - Aplicación BeeWi HeliPad compatible con los aparatos Android, versión 2.1 y superior - Mandos intuitivos que utilizan el sensor de orientación y la interfaz táctil del móvil - 2 modos de control: normal y experto 1.3. Presentación del producto 1. Palas (2) 2. Hélice trasera 3. Estabilizador 4. Luz frontal 1.4. Especificaciones Tecnología Bluetooth 3.
- Durante la carga, el indicador luminoso se apaga; cuando se vuelve a encender significa que la batería está cargada. 2.2. Instalación de la aplicación BeeWi HeliPad Acceda a Android Market y busque la aplicación "BeeWi HeliPad". Siga las instrucciones de descarga e instale la aplicación. Una vez instalada la aplicación, puede iniciarla directamente. Asegúrese de que el helicóptero se haya emparejado y conectado previamente al móvil antes de utilizarlo. 2.3.
abriendo el menú "Select Helicopter" y buscando el helicóptero. En este caso, seleccione el aparato ‘BeeWi BBZ301’ en la pantalla e introduzca el código ‘0000’ para añadirlo a la lista de emparejamiento. - Durante la carga, el indicador luminoso se apaga; cuando se vuelve a encender significa que la batería está cargada. 3. Utilización del helicóptero 3.1.
3.2. Utilización Cuando el helicóptero está conectado, se puede acceder a la pantalla de controles. De manera predeterminada, el control se realiza mediante el sensor de movimiento y el ajuste de dirección (trimmer) está en la posición cero. 1. Palanca de gas 2. Mando de dirección 3. Trimmer 4. Modo de pilotaje 5. Control táctil/ movimiento Empuje suavemente los mandos de gas hasta que el helicóptero se ponga en marcha.
Una vez que se han adquirido los controles de dirección, puede volar su helicóptero. Empuje suavemente el mando de gas hasta que el helicóptero despegue y trate de mantenerlo a una altitud estable. Una vez que controle perfectamente el mando de gas, puede empezar a utilizar todos los controles y entrenarse para seguir los siguientes circuitos. 3.3. Configuración La tecla Menú del móvil permite acceder al menú de configuración.
4. Mantenimiento y precauciones de uso Atención: - Lea atentamente el manual completo y siga estrictamente las instrucciones antes del vuelo. - Este producto no está destinado a niños de menos de 14 años. - Este producto no es adecuado para niños pequeños – riesgos de rotura y asfixia por ingestión de piezas pequeñas. - Mantenga las distancias cuando el producto está en funcionamiento. No se acerque demasiado ni toque las piezas giratorias.
Declaración de conformidad con Directivas de Unión Europea Por la presente, VOXLAND declara que este producto cumple: • Los requisitos esenciales y otras estipulaciones relevantes de la Directiva 1999/5/EC. • Todas las demás Directivas relevantes de la UE. Puede ver la Declaración de Conformidad (DoC) de su producto con la Directiva 1999/5/EC (según Directiva R&TTE) en www.bee-wi.com. Reciclaje para el Cuidado del Medio Ambiente No deposite sus aparatos o accesorios electrónicos en la basura de su casa.
Muito obrigado por ter escolhido o helicóptero telecomandado Bluetooth BBZ301 da BEEWI. Leia as instruções que se seguem para configurar e utilizar o seu aparelho da melhor forma. Introdução O helicóptero telecomandado BBZ301 pode ser controlado directamente pelo seu Smartphone utilizando a aplicação específica BeeWi HeliPad disponível no Android Market. O helicóptero Bluetooth funciona como um helicóptero telecomandado convencional com comandos de gás e direcções frente/trás e esquerda/direita.
- Aplicação BeeWi HeliPad compatível com os aparelhos Android, versão 2.1 e superior - Comandos intuitivos que utilizam o sensor de orientação e a interface táctil do telemóvel - 2 modos de controlo: normal e perito 1.3. Apresentação do produto 1. Pás (2) 2. Hélice traseira 3. Estabilizador 4. Luz frontal 1.4. Especificação Tecnologia Bluetooth 3.
suavidade. - Durante o carregamento, o indicador luminoso apaga-se; caso se acenda de novo, isso significa que a bateria está carregada. 2.2. Instalação da aplicação BeeWi HeliPad Vá a Market e procure a aplicação "BeeWi HeliPad". Siga as indicações para descarregar e instalar a aplicação. Uma vez a aplicação instalada, pode iniciá-la directamente. Certifique-se de que o helicóptero foi previamente emparelhado e ligado ao telemóvel antes da utilização. 2.3.
abrindo o menu “Select Helicopter” e procurando o helicóptero. Neste caso, seleccione o aparelho “BeeWi BBZ301” no ecrã e introduza o código “0000” para adicionar este aparelho à lista de emparelhamento. 3. Utilização do helicóptero 3.1. Ligação Abra a aplicação BeeWi HeliPad e visualize os menus utilizando a tecla Menu do telemóvel e active o menu “Select Helicopter’ para visualizar os aparelhos emparelhados. 1 2 1 2 Certifique-se de 4que o helicóptero está a funcionar e seleccione-o na lista.
3.2. Utilização Quando o helicóptero é ligado, o ecrã de controlos fica acessível. Por defeito, o controlo é efectuado utilizando o sensor de movimento e a regulação de direcção (trimmer) é ajustada para zero. 1. Manete de gás 2. Alavanca de direcção 3. Trimmer 4. Mdo de pilotagem 5. Controlo Táctil/ Movimento Carregue suavemente nos comandos de gás até que o helicóptero comece a funcionar.
Uma vez os comandos de direcção adquiridos, pode fazer voar o helicóptero. Carregue suavemente no comando de gás até o helicóptero começar a voar e tente mantê-lo a uma altitude estável. Uma vez o comando de gás devidamente dominado, pode começar a utilizar a totalidade dos comandos e treinar-se a seguir os circuitos seguintes. 3.3. Configuração O menu de configuração é acessível a partir da tecla Menu do telemóvel.
4. Manutenção e precauções de utilização Atenção: - Leia com atenção o manual completo e siga rigorosamente as instruções que lhe são fornecidas antes do voo. - Este produto não se destina a crianças com menos de 14 anos. - Este produto não é adequado para crianças de tenra idade – riscos de quebra e de sufocação por ingestão de peças pequenas. - Mantenha as distâncias devidas quando o produto se encontra em funcionamento. Não se aproxime demasiado nem toque nas partes em rotação.
Declaração de Conformidade com as Directivas da União Europeia A VOXLAND declara pela presente que este produto está em conformidade com: • Os requisitos essenciais e outras disposições relevantes da Directiva 1999/5/CE • Todas as outras Directivas relevantes da UE Pode visualizar a Declaração de Conformidade (DdeC) do nosso produto com a Directiva 1999/5/CE (para a Directiva ETRT) em www.bee-wi.com.
Wij danken u voor uw keuze van de helikopter met Bluetooth afstandsbediening BBZ301 van BEEWI. Gelieve de volgende instructies door te lezen, om uw apparaat zo goed mogelijk te kunnen configureren en gebruiken. Inleiding De helikopter met afstandsbediening BBZ301 kan rechtstreeks bestuurd worden door uw Smartphone met behulp van de speciale applicatie BeeWi HeliPad die te vinden is op Android Market.
- Standaard USB lading - Applicatie BeeWi HeliPad compatibel met de Android apparaten, versie 2.1 en hoger - Intuïtieve bediening met behulp van de oriëntatiedetector en de touch interface van de mobiele telefoon - 2 controlemodi: normal en expert 1.3. Presentatie van het product 1. Schroefbladen (2) 2. Achterste propeller 3. Slinger 4. Lamp voorzijde 1.4.Specificatie Technologie Bluetooth 3.0 Bereik Protocol Accu Autonomie Oplaadtijd Servo-controles Afmetingen Gewicht Klasse 2, min. 10 m, max.
moet rustig tot stand komen. - Tijdens het opladen dooft het controlelampje; als het opnieuw gaat branden, betekent dit dat de accu opgeladen is. 2.2. Installatie van de applicatie BeeWi HeliPad Ga naar Market en zoek de applicatie « BeeWi HeliPad ». Volg de aanwijzingen voor het downloaden en installeren van de applicatie. Wanneer de applicatie eenmaal geïnstalleerd is, kunt u deze onmiddellijk opstarten.
N.B.: U kunt de helikopter rechtstreeks in de applicatie koppelen via het menu “Select Helicopter”, waarin u de helikopter zoekt. Selecteer in dat geval het apparaat ‘BeeWi BBZ301’ op het beeldscherm en voer de ‘0000’ in om dit apparaat aan de koppelingslijst toe te voegen. 3. Gebruik van de helikopter 3.1.
3.2. Gebruik Wanneer de helikopter verbinding heeft gemaakt, wordt het controlescherm toegankelijk. Standaard wordt de controle uitgevoerd met behulp van de bewegingsdetector en de instelling van de richting (trimmer) staat op nul. 1. Gashendel 2. Richtingshendel 3. Trimmer 4. Besturingswijze 5. Controle Touch/ Beweging Geef voorzichtig gas totdat de helikopter begint te werken.
Wanneer u de richtingscommando's goed beheerst, kunt u uw helikopter laten vliegen. Duw rustig tegen de gashendel totdat de helikopter opstijgt en probeer hem op een stabiele hoogte te houden. Wanneer u het gasgeven goed beheerst, kunt u beginnen alle commando's te gebruiken en u trainen in het volgen van de volgende banen. 3.3. Configuratie Het configuratiemenu is toegankelijk via de Menutoets van de mobiele telefoon.
4. Onderhoud en voorzorgsmaatregelen bij gebruik Let op! - Gelieve de complete handleiding aandachtig door te lezen en de instructies die u voor het vliegen krijgt, nauwkeurig op te volgen. - Dit product is niet geschikt voor kinderen onder de 14 jaar. - Dit product is niet geschikt voor kleine kinderen - risico van breuk en verstikking door het inslikken van kleine elementen. - Blijf op afstand wanneer het product werkt. Niet te dicht bij de draaiende delen komen en deze niet aanraken.
Europese Unie Richtlijnen Conformiteitsverklaring Hierbij verklaart VOXLAND dat dit product overeenkomstig is met: • De essentiële vereisten en andere toepasselijke bepalingen onder Richtlijn 1999/5/EC • Alle andere toepasselijke EU richtlijnen U kan de conformiteitsverklaring van uw product onder Richtlijn 1999/5/EC (met R&TTE Richtlijn) bekijken op www.bee-wi.com. Draag uw steentje bij aan een beter milieu door te recycleren Gooi geen elektrische toestellen of accessoires bij uw huishoudelijk afval.
Благодарим ви, че избрахте дистанционно управляемия хеликоптер Bluetooth BBZ301 на BEEWI. Бъдете така добри да прочетете следните инструкции, за да можете да конфигурирате и използвате по-добре вашият уред. Увод Дистанционно управляемият хеликоптер BBZ301 може да се управлява направо от вашия Smartphone, като се използва специалното приложение BeeWi HeliPad на разположение в Android Market.
- Стандартно USB зарядно - Приложение BeeWi HeliPad съвместимо с уредите Android, версия 2.1 и по-висока - Интуитивен контрол, използвайки сензор за ориентация и сензорния интерфейс на мобилния телефон - 2 режима на контрол: нормален и експертен 1.3. Представяне на продукта 1. Перки (2) 2. Задна перка 3. Балансер 4. Предна светлина 1.4 Спецификация Технология Bluetooth 3.
внимателно. - По време на зареждането, светлинният датчик се изключва; ако той се включи отново, това означава, че акумулаторът е зареден 2.2 Инсталиране на приложението BeeWi HeliPad Идете в Market и потърсете приложението «BeeWi HeliPad». Следвайте указанията, за да свалите и инсталирате приложението. След като приложението бъде инсталирано, можете да го стартирате директно. Уверете се, че хеликоптерът е бил предварително сдвоен и свързан към мобилния телефон преди употреба. 2.3.
N.B.: Забележка: възможно е да сдвоите хеликоптера директно направо в приложението, като отворите менюто “Select helicopter” (Избери хеликоптер) и като потърсите хеликоптера. В този случай, изберете уреда ‘BeeWi BBZ301’ от екрана и въведете кода ‘0000’, за да добавите този уред към списъка за сдвояване. 3. Употреба на хеликоптера 3.
3.3 Употреба Когато хеликоптерът е свързан, контролният екран е достъпен. По подразбиране контролът се осъществява използвайки сензор за движение и регулиране на посоката (тример), които са на нула. 1. Ръчка за газ 2. Лост за посоките 3. Тример 4. Режим на пилотиране 5. Сензорен контрол/ движение Леко натиснете газта, докато хеликоптерът се задейства.
След като командите за управление са получени, можете да накарате вашия хеликоптер да лети. Леко натиснете командата на газта докато хеликоптерът полети и се опитайте да го поддържате на стабилна височина. След като командата за газта е добре усвоена, можете да започнете да използвате всички команди и да се упражнявате да следвате следните контроли. 3.3 Конфигурация Менюто за конфигурация е достъпно от клавиша Меню на мобилния телефон..
4. Поддръжка и предпазни мерки при употреба 4. Поддръжка и предпазни мерки при употреба Внимание: - Благодарим ви, че прочетохте внимателно целия наръчник и че следвате инструкциите, които са ви дадени преди полета. - Този продукт не е предназначен за деца на по-малко от 14 години. - Този продукт не е подходящ за малки деца – има риск от счупване и задушаване при поглъщането на малки частици. - Спазвайте дистанция, когато продуктът е включен.
Декларация за съответствие на директивите на Европейския съюз VOXLAND заявява, че този продукт е в съответствие с: • Основните разпоредби, както и на всички приложими разпоредби на Директива 1999/5/EC • Всички други приложими директиви на Европейския съюз Можете да видите Декларацията за съответствие (DoC) на директива 1999/5/EC (Директива R&TTE) на сайта www.bee-wi.com. Защита на околната среда чрез рециклиране Когато върху даден продукт фигурира този символ, не го изхвърляйте в кофата си за боклук.
Vă mulţumim pentru că aţi ales elicopterul cu telecomandă Bluetooth BBZ301 de la BEEWI. Vă rugăm să citiţi instrucţiunile următoare pentru a configura şi utiliza optim aparatul dvs. Introducere Elicopterul cu telecomandă BBZ301 poate fi controlat direct prin propriul dvs. Smartphone, folosind aplicaţia specifică BeeWi HeliPad disponibilă pe Android Market.
- Încărcare USB standard - Aplicaţie BeeWi HeliPad compatibilă cu aparatele Android, versiunile 2.1 şi superioare - Comenzi intuitive, folosind senzorul de orientare şi interfaţa tactilă a mobilului - 2 moduri de comandă: normal şi expert 1.3 Prezentarea produsului 1. Pale (2) 2. Elice spate 3. Balansier 4. Lumină frontală 1.4. Specificaţii Tehnologie Bluetooth 3.
stinge; dacă se aprinde din nou, aceasta înseamnă că bateria s-a încărcat. 2.2 Instalarea aplicaţiei BeeWi HeliPad Mergeţi la Market şi căutaţi aplicaţia „BeeWi HeliPad“. Urmaţi indicaţiile pentru descărcarea şi instalarea aplicaţiei. Odată aplicaţia instalată, puteţi să o lansaţi direct. Înainte de utilizare, asiguraţi-vă că elicopterul a fost cuplat şi conectat la mobil. 2.
Utilizarea elicopterului 3.1 Conectare Deschideţi aplicaţia BeeWi HeliPad şi afişaţi meniurile, folosind tasta Meniu a mobilului, apoi activaţi meniul „Select helicopter” („Alegere elicopter“) pentru a afişa aparatele cuplate. 1 2 1 2 4 Asiguraţi-vă că elicopterul este pornit şi selectaţi-l din listă. Elicopterul va fi conectat automat şi va deveni accesibil ecranul de comandă următor.
3.2. Utilizare După ce elicopterul este conectat, devine accesibil ecranul de comandă. Comanda este efectuată implicit prin folosirea senzorului de mişcare, iar reglajul direcţiei (trimmer) este la zero. 1. Regulator 2. Manetă de direcţie 3. Trimmer 4. Mod de pilotare 5. Control tactil/ Deplasare Împingeţi uşor regulatorul până când elicopterul intră în funcţiune.
Odată deprinse comenzile de direcţie, puteţi să faceţi elicopterul să zboare. Împingeţi uşor regulatorul până când elicopterul se ridică şi încercaţi să-l menţineţi la o altitudine stabilă. Odată comanda regulatorului bine stăpânită, puteţi începe să folosiţi toate comenzile şi să vă antrenaţi pentru a parcurge circuitele următoare. 3.3 Configurare Meniul de configurare este accesibil prin intermediul tastei Meniu a mobilului.
4. Întreţinere şi precauţii de utilizare Atenţie: - Vă rugăm să citiţi cu atenţie manualul complet şi să urmaţi strict instrucţiunile oferite înainte de zbor. - Acest produs nu este destinat copiilor sub 14 ani. - Acest produs nu este adecvat pentru copii cu vârste mici – risc de spargere şi sufocare prin ingerarea unor piese mici. - Păstraţi distanţa atunci când produsul este în funcţiune. Nu vă apropiaţi prea mult şi nu atingeţi părţile aflate în rotaţie.
Declaraţie de conformitate cu directivele Uniunii Europene VOXLAND declară că acest produs este conform cu: • Dispoziţiile principale şi toate celelalte prevederi aferente directivei 1999/5/CE • Orice alte directive aferente ale Uniunii Europene Puteţi vizualiza Declaraţia de Conformitate (DoC) cu directiva 1999/5/CE (cu directiva R&TTE) pe site-ul www.bee-wi.com Protecţia mediului prin reciclare Dacă pe produs este afişat acest simbol, nu-l aruncaţi la gunoi.
© VOXLAND, 2011.
