Operating instructions
Table Of Contents
- Front cover
- Table of contents
- Contents
- General
- Warranty
- Safety instructions
- Intended use
- Assembling and disassembling the plug-in connecting cable
- Installation
- Assembling the drive
- Undoing the mounting pin
- Drive adapter for obstacle detection
- Assembling the drive adapter with drive adapter safety catch
- Assembling the drive adapter with screw connection
- Securing the drive against axial displacement
- Fixing the drive adapter to the barrel dia. 45
- Mounting the drive in the tube
- Confirming the drive
- First operation
- Programming the master transmitter
- Checking that the running direction is correct
- Intelligent installation management
- Setting the limit positions
- Changing the set limit positions
- Deleting the limit positions
- Intermediate positions I + II
- Programming additional transmitters
- Deleting transmitters
- Overwriting the master
- Upper anti-freeze mechanism
- Obstacle detection
- Fly screen protection function
- Programming the run times
- Deleting the run times
- Disposal
- Maintenance
- Technical data dia. 45
- What to do if...?
- Sample wiring diagram
- Declaration of conformity
- Last page
Warranty
Structural modifications and incorrect installation which are not in accordance with these and our other instructions can result in
serious injuries, e.g., crushing of limbs. Therefore, structural modifications may only be carried out with our prior approval and
strictly in accordance with our instructions, particularly the information contained in these Assembly and Operating Instructions.
Any further processing of the products which does not comply with their intended use is not permitted.
The end product manufacturer and fitter have to ensure that all the relevant current statutory, official and, in particular, EMC regu‐
lations are adhered to during utilisation of our products, especially with regard to end product manufacture, installation and cus‐
tomer advice.
Safety instructions
The following safety instructions and warnings are intended to avert hazards and to prevent property damage and personal injury.
Please keep these instructions in a safe place.
Caution
Important safety instructions for the user.
Failure to observe these instructions can lead to serious injuries.
▪ All work, including maintenance and cleaning, on electrical installations as well as other system parts must
always be performed by authorised specialists, in particular qualified electricians.
▪ Do not allow children to play with control units.
▪ Systems have to be checked regularly by authorised specialists for wear and damage.
▪ Always put damaged systems out of operation immediately until they are repaired by an authorised special‐
ist.
▪ Do not operate equipment if people or objects are within the danger zone.
▪ Observe the danger zone of the equipment during operation.
▪ Stop and disconnect the equipment from the mains power supply when maintenance and cleaning is being
performed either on the system itself or in the immediate vicinity of it.
▪ Ensure that there is adequate clearance (at least 40 cm) between moving parts and adjacent objects.
▪ Crushing or shearing points must be avoided or protected.
