General
These tubular drives are high-quality products with the following features:
▪ Optimised for roller shutter operation
▪ Individual, group and central radio control
▪ No need to run wires to a switch or relay control device
▪ Any combination of drive and transmitter possible
▪ Simple to set the limit positions with the transmitter
▪ Installation without stops possible (from upper point to lower point)
▪ Two freely selectable intermediate positions can be set
▪ Flexible radio grouping; can be altered at any time with no need to install/uninstall
▪ Integrated memo function facilitates easy programming of one or two switching times on daily repeat.
▪ Automatic detection of the lower limit position when using springs in conjunction with the "drive adapter for obstacle detection"
▪ Automatic detection of limit positions thanks to intelligent electronic system with stop systems
▪ Obstacle detection, even when using anti-lifting devices (axle shaft devices)
▪ Secure anti-lifting device
▪ Slight pressure applied to the roller shutter curtain makes it difficult to raise or reach under it
▪ Suitable for rigid aluminium, steel and wooden profiles
▪ The final positions do not have to be reset: Changes in the shading solution are accommodated automatically when using stop
systems.
▪ Torque control in the up direction prevents damage to the roller shutter in the event of a frozen or blocked shutter
▪ Anti-freeze mechanism in the upper limit position can be enabled
▪ Considerably lower stop load, and thus considerably lower shading solution load.
▪ Smooth operation of the system and the drive increases the service life
▪ For plug-in connecting cable
▪ Fly screen protection function
Please observe these Assembly and Operating Instructions when installing and setting the equipment.
Note
In order to identify the type of drive, compare the type plate of the tubular drive with the cover of these in‐
structions.
