Deleting the run times
Note
When deleting, both run times are always deleted.
To delete the UP and DOWN run time, press the STOP button for 10 seconds. The tubular drive makes a "click click" sound to
confirm.
The run times are now deleted.
Disposal
This product is made of various materials which must be disposed of properly. Find out about the applicable regulations on recy‐
cling or disposal for this product in your country.
The packaging material must be disposed of properly.
Maintenance
These drives are maintenance-free.
Technical data dia. 45
Type R12/17C
PROF+A2
R20/17C
PROF+A2
R30/17C
PROF+A2
R40/17C
PROF+A2
Rated torque (Nm) 12 20 30 40
Output speed (rpm)
17 17 17 17
Limit switch range 64 revolutions
Supply voltage 230 V AC / 50 Hz
Connected load (W) 110 160 205 260
Rated current consumption (A) 0.5 0.75 0.9 1.15
Mode S2 4 min
Protection type IP 44
Min. tube inside diameter (mm) 47
Frequency 915.3 MHz
21
