Installation & Assembly

Part List
Kitchen Island
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Tools required for assembly : Phillips screwdriver
A1.
Top
1 pc.
J.
Stretcher
1 pc.
H1.
Front Rail
1 pc.
R.
Leg Support
1 pc.
Q.
Plinth
2 pcs.
O.
Back Support
1 pc.
N.
Back Support
1 pc.
V.
Drawer
1 pc.
Also need the following from carton
Hardware List in carton
Hex Wrench
Small Hex Wrench
Cam Lock Screw
Cam Lock
Head Cap Bolt
Adjustable Pin
Pull Handle
Knob
Machine Screw
Wood Screw (long)
Wood Screw (short)
Wood Screw for Hinge
1 pc.
1 pc.
16 pcs.
16 pcs.
24 pcs.
20 pcs.
2 pcs.
2 pcs.
6 pcs.
8 pcs.
6 pcs.
27 pcs.
Tools recommended for assembly :Level
A2.
Top
1 pc.
Part List in carton
Side Panel (B)
Side Panel (C)
Side Panel (D)
Side Panel (E)
Side Panel (F)
Side Panel (G)
Front Rail (H2)
Back Stretcher (I)
Back Panel (K)
Shelf (L)
Shelf (M)
Base (P)
1 pc.
1 pc.
1 pc.
1 pc.
1 pc.
1 pc.
2 pcs.
2 pcs.
2 pcs.
4 pcs.
1 pc.
1 pc.
Part List in carton
Plinth (S)
Door (T)
Door (U)
2 pcs.
1 pc.
1 pc.
