Datasheet
www.baumer.com/motion
Inclination sensors
3
Subject to modication in technic and design. Errors and omissions excepted.1/2/2019
GIM500R - 2-dimensional
2-dimensional, measuring range up to ±90°
CANopen® / SAE J1939 / Analog
Accessories
Connectors and cables
10127844 Connection cable 2 m shielded with female
connector M12, 8-pin, straight (ESG
34FH0200G)
10129332 Connection cable 5 m shielded with female
connector M12, 8-pin, straight (ESG
34FH0500G)
10129333 Connection cable 10 m shielded with female
connector M12, 8-pin, straight (ESG
34FH1000G)
Mounting accessories
11120131 Mounting kit 3x M4 x 25 DIN912, A 4.3
DIN125
11189609 Mounting kit 3x M4 x 50 DIN912, A 4.3
DIN125, spacers
General information
Self-heating correlated to installation and ambient condi-
tions as well as to electronics and supply voltage must be
considered for precise thermal dimensioning. The inclina-
tion sensor is supposed to self-heating to approximately
5 K when attached to a varnished ground metal. Operating
the inclination sensor close to the maximum limits requires
measuring the currently prevailing temperature at the hous-
ing.
Vibration with frequency in the range of 1600 Hz acting on
the sensor leads to reduced measuring accuracy.
CANopen® features
Bus protocoll CANopen®
Device prole CANopen® - CiA DSP 301 V4.2
Inclinometer prole DS 410 V1.3
LSS service prole DS 305 V2.2
Default Resolution 0.1°
Baud rate 50 kbit/s
Node ID 1
Zero setting
SetTeachinputfor>250msonHIGHlevel(≥0.7*+Vs)
conforms inclination 0°.
Zero setting affects both axes (X/Y).
