Datasheet

www.baumer.com/motion
Cable transducer
3
Subject to modication in technic and design. Errors and omissions excepted.11/6/2019
Flange connector M12, male, 5-pin
Pin Signals Description
1 0 V Ground connection relating to +Vs
2 +Vs Voltage supply
3 Uout/lout Output
4 n.c. Do not use
5 n.c. Do not use
1
2
3
4
5
Flange connector M12, male, 8-pin, redundant version
Pin Signals Description
1 0 V1 Ground connection
relating to +Vs1
2 +Vs1 Voltage supply 1
3 Uout1/lout1 Output 1
4 0 V2 Ground connection
relating to +Vs2
5 +Vs2 Voltage supply 2
6 Uout2/lout2 Output 2
7 n.c. Do not use
8 n.c. Do not use
1
3
4
2
5
6
7
8
Cable
Core colour Signals Description
white 0 V Ground connection relating to +Vs
brown +Vs Voltage supply
green Uout/lout Output
Cable data: 3 x 0.5 mm
2
, 2 m
Cable redundant version
Core colour Signals Description
white 0 V1+2 Ground connection
relating to +Vs1
and +Vs2
brown +Vs1 Voltage supply 1
green Uout1/lout1 Output 1
yellow +Vs2 Voltage supply 2
grey Uout2/lout2 Output 2
Cable data: 5 x 0.5 mm
2
, 2 m
Terminal assignment
GCA5 - analog
Analog output
Measuring length absolute 2.3 m and 4.7 m
