Datasheet

Cable transducer

www.baumer.com/motion

Subject to modication in technic and design. Errors and omissions excepted.11/6/2019

GCA5 - analog

Part number

GCA5-PM .RA . 0.A

Voltage supply / interface

V3 8...30 VDC / Analog 0.5...4.5 VDC

V6 12...30 VDC / Analog 0...10 VDC

C0 12...30 VDC / Analog 4...20 mA

R3 8...30 VDC / Analog 0.5...4.5 VDC redundant

R6 12...30 VDC / Analog 0...10 VDC redundant

R0 12...30 VDC / Analog 4...20 mA redundant

Connection

L Cable radial, 2 m

N Flange connector M12, 5-pin, radial, male contacts, CCW

B Flange connector M12, 8-pin, radial, male contact, CCW redundant

Measuring range

023 2.3 m

047 4.7 m

Analog output

Measuring length absolute 2.3 m and 4.7 m
