User Manual

G96 Series CE Approved Gas Valve Installation Instructions 5
Technical Data
Product G96 Series BASOTROL CE Approved Gas Valve
Types of Gas 2nd (Natural Gas), and 3rd (LP Gas) Family Gases
Permissible Ambient
(Surface) Temperature
-20 to 175°F (-29 to 79°C)
Electrical Ratings 12 VDC, 1.0A
25 VAC, 50/60 Hz, 0.595A
120 VAC, 50/60 Hz, 0.13A
240 VAC, 50/60 Hz, 0.063A
Maximum Operating
Pressure
North America:
Europe:
0.5 psi
100 mbar
Maximum Differential
Pressure
8 in. W.C. (20 mbar [2 kPa])
Reverse Pressure Ratings 20 in. W.C. (50 mbar [5 kPa]) Minimum; Class B (EN 126 and 161)
Regulator Classification Class C (EN 126)
Regulator Setting Factory set to customer’s specification
Regulator Adjustment
Range
Top Adjust Regulators: 3 to 6 in. W.C. (7.5 to 15 mbar)
6 to 12 in. W.C. (15 to 30 mbar)
Inlet Pipe Size 1/2 in. Rp or 1/2 in. NPT
Outlet Pipe Size 1/2 in. Rp or 1/2 in. NPT
Valve Torsion Group Group 2 (EN 126 and EN 161)
Pressure Connection 1/8 in. Rp or 1/8 in. NPT Outlet Tap
Pilot Connections 1/8 in. Rp or 1/8 in. NPT Left-hand and Right-hand
Dirt Strainer 0.036 in. (0.9 mm) Mesh
Operating Time Rating 100% Continuous
Valve Timings Closing Time
Opening Time
Dead Time
<
1 Second
<
1 Second
<
1 Second
Power Ratings 15 VA per Coil
Electrical Connections 3-Tab Solenoid Coil
2-Tab Solenoid Coil
2 x 1/4 in (6.35 mm) Tabs + 1/4 in. (6.35 mm) Earth Ground Tab
2 x 1/4 in. (6.35 mm) Tabs
Coil Insulation Class Class F
Accessories Conversion Kits Natural Gas to LP Gas:
LP Gas to Natural Gas:
Non-Regulation:
Top Adjust Regulator
Top Adjust Regulator
Top or Bottom Adjust Regulator
Y71GF-4
Y71QH-2
Y71AA-5
Packaging Bulk pack supplied to original equipment manufacturer (individual pack optional).
Bulk Pack Quantity 10 per carton
Bulk Pack Weight 26 lb (12 kg) per carton
