Operating elements

2 3

6 7

1 Transmitter

2 Red LED: ULTRA mode indicator

3 Green LED: TRANS mode indicator

4 Speaker: Ultrasonic sound

5 Mode switch:

TEST, ULTRA, TRANS, DUO

6 Intensity switch (1, 2, 3/low, medium, high)

7 Power input socket

Operation

1. Connect one end of the adaptor to a power outlet and the other end to the input socket on the product.

2. Slide the 4-function switch to choose a mode.

Switch Indicator LED Description

TEST Red ON

Test tone

This simulates the sound that rodents hear. It is for reference

only and does not repel. Do not use.

ULTRA Red ON Ultrasonic sound: Repels mice

TRANS Green blinking Ultrasonic sound: Repels rats and squirrels

DUO

Red ON

Green blinking

ULTRA + TRANS

Repels mice, rats, and squirrels.

3. Slide the intensity switch to select the intensity of the signal (1, 2, 3/low, medium, high).

Tips on use

• It is effective when used continuously over a period of time.

• It should be placed at ground level.

• There should be no obstacles in front of the speakers.

Care and cleaning

• Disconnect the product from the mains before each cleaning.

• Do not use any aggressive cleaning agents, rubbing alcohol or other chemical solutions as they can

cause damage to the housing and malfunctioning.

• Clean the product with a dry, bre-free cloth.

Disposal

Electronic devices are recyclable waste and must not be disposed of in the household waste.

At the end of its service life, dispose of the product in accordance with applicable regulatory

guidelines.

You thus fulll your statutory obligations and contribute to the protection of the environment.

Technical data

a) Product

Input voltage/current ............................. 9 V/DC 200 mA

Protection class .................................... III

Effective range ......................................max. 100 m

Frequency ranges ................................. Ultrasonic frequency: 22 - 33 kHz, Trans frequency: 23.5 - 24.5 kHz

Accoustic pressure ............................... 90 dB

Operating conditions ............................. -10 to +40 ºC, 30 – 85 % RH (non-condensing)

Storage conditions ................................ -10 to +60 ºC, 30 – 85 % RH (non-condensing)

Dimensions (W x H x D) ....................... 120 x 104 x 92 mm

Weight ..................................................210 g

b) Power adapter

Input voltage/current ............................. 100 - 240 V/AC, 50/60 Hz, 0.2 A

Output voltage/current .......................... 9.0 V/DC, 500 mA

Protection class .................................... II

Weight ..................................................57 g

Operating Instructions

Ultrasonic pest repeller

Item No. 2346562

Intended use

The product uses dual ultrasound waves to repel

creatures such as rats, mice, and squirrels.

It is intended for indoor use only. Do not use it out-

doors. Contact with moisture, e.g. in bathrooms,

must be avoided under all circumstances.

For safety and approval purposes, you must not re-

build and/or modify this product. If you use the prod-

uct for purposes other than those described above,

the product may be damaged. In addition, improper

use can result in short circuits, res, electric shocks

or other hazards. Read the instructions carefully and

store them in a safe place. Make this product avail-

able to third parties only together with its operating

instructions.

This product complies with the statutory national and

European requirements. All company names and

product names are trademarks of their respective

Delivery content

• Product

• Power adapter

• Operating instructions

Up-to-date operating instructions

Download the latest operating instructions at

www.conrad.com/downloads or scan the QR code

shown. Follow the instructions on the website.

Explanation of symbols

The symbol with the lightning in the

triangle is used if there is a risk to your

health, e.g. due to an electric shock.

The symbol with the exclamation mark in

the triangle is used to indicate important

information in these operating instruc-

tions. Always read this information care-

fully.

The product must only be installed and

used in dry, indoor locations. It must not

become damp or wet, as this may cause

a fatal electric shock!

This product is constructed according to

protection class III.

Safety instructions

Read the operating instructions

carefully and especially observe

the safety information. If you do not

follow the safety instructions and

information on proper handling in

this manual, we assume no liability

for any resulting personal injury or

damage to property. Such cases will

invalidate the warranty/guarantee.

• The appliance is not to be

used by persons (includ-

ing children) with reduced

physical, sensory or mental

capabilities, or lack of expe-

rience and knowledge, un-

less they have been given

supervision or instruction.

• Children shall be supervised

not to play with the appli-

ance

a) General information

• The device is not a toy. Keep it out of the reach

of children and pets.

• Do not leave packaging material lying around

carelessly. This may become dangerous playing

material for children.

• Protect the appliance from extreme tempera-

tures, direct sunlight, strong jolts, high humidity,

moisture, ammable gases, steam and solvents.

• Do not place the product under any mechanical

stress.

• If it is no longer possible to operate the product

safely, take it out of operation and protect it from

any accidental use. Safe operation can no longer

be guaranteed if the product:

- is visibly damaged,

- is no longer working properly,

- has been stored for extended periods in poor

ambient conditions or

- has been subjected to any serious transport-

related stresses.

- Please handle the product carefully. Jolts,

impacts or a fall even from a low height can

damage the product.

• Consult an expert when in doubt about the op-

eration, safety or connection of the appliance.

• Maintenance, modications and repairs must

only be completed by a technician or an author-

ised repair centre.

• If you have questions which remain unanswered

by these operating instructions, contact our tech-

nical support service or other technical personnel.

b) Product

• Never connect the product to the power supply

immediately after it has been transferred from

a cold room into a warm one. Risk of electric

shock! Allow the product to reach room tempera-

ture. Wait until the condensation has evaporated.

This might take several hours. Only then the

product may be plugged into the mains socket

and put into use.

• Do not operate while covered. Risk of re!

• Never pour any liquids above or next to the prod-

uct. You run the risk of causing a re or a fatal

electric shock! First, power down the respec-

tive mains socket (e.g. via the respective circuit

breaker) and then carefully pull the mains plug

from the mains socket.

• Do not use the product near people, espe-

cially children! The human ear can detect part

of the ultrasonic waves produced. Prolonged

exposure may result in hearing damage.

• Do not use the product within range of pets

such as rabbits, guinea pigs, hamsters, dogs

etc. The product may cause them varying de-

grees of distress.

c) Power adapter

• Connect the appliance to a wall socket that can

be accessed easily.

• As power supply, only use the supplied mains

adaptor.

• Only connect the power adaptor to a normal

mains socket connected to the public supply.

Before plugging in the power adaptor, check

whether the voltage stated on the power adap-

tor complies with the voltage of your electricity

supplier.

• Never connect or disconnect power adaptors if

your hands are wet.

• Never unplug the power adaptor from the mains

socket by pulling on the cable; always use the

grips on the plug.

• When setting up the product, make sure that

the cable is not pinched, kinked or damaged by

sharp edges.

• Always lay the cables so that nobody can trip

over or become entangled in them. This poses

a risk of injury.

• For safety reasons, disconnect the power adap-

tor from the mains socket during storms.

This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights in-

cluding translation reserved. Reproduction by any method, e.g. photocopy, microlming, or the capture in electronic data

processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication

represent the technical status at the time of printing.
