Installation and connectionbĵb 41

Installation and connection

This page describes the process of installation and connection of the outdoor panel.

Ŀ Completeness check of the product

(see page 41)

Ŀ Electrical connection(see page 41)

Ŀ Mechanical mounting(see page 45)

Ŀ Connection of additional modules(see page 46)

Completeness check of the product

Before installation of the outdoor panel, it is necessary to check that it is complete and all

components are available.

Outdoor panel kit includes:

Outdoor panel 1 pcs

Flush mount bracket 1 pcs

Installation instructions 1 pcs

Set of wires with connectors for connection of power supply, lock,

and additional modules.

1 pcs

A set of plugs for connections 1bpcs

Wrench set screws 1bpcs

Electrical connection

After verifying whether a device is complete, you can switch to the connection step.

For connection you will need:

Ŀ An Ethernet UTP CAT5 or higher cable connected to a network switch/router.b

Ŀ Power supply at  12V, 2 amps.b

Ŀ Wires must be brought for connecting the lock and additional modules (optional).b

The following are typical connection schemes of all elements to the outdoor panel:

Cable lenght recomendations

The maximum length of the UTP CAT5 cable segment should not exceed 100 meters,

according to the IEEE 802.3 standard.

You can connect any type of electromechanical or electromagnetic lockbfor which the

switched current does not exceed 5 Amps.
