INSTALLER SECTION
3. TECHNICAL DATA AND USEFUL INFORMATION ON PUMPS
3.1 Emptying pump (optional)
How installing, pay particular attention to the position of the emptying tube (see pict. 7).
See chapter 5.3. for operations description.
3.2 Pressure increasing pump (optional)
When the dishwasher has not been used for some time, check that the supplementary
pressure increasing pump turns freely.
To do this, operate using a screwdriver in the special slot on the ventilating side of the motor
shaft (see pict. 8).
In case of blocking, turn the main switch off and move the motor shaft, inserting the
screwdriver in the notch, turning it clockwise and anticlockwise.
MAX 0,8m
pict. 8
CAUTION: INCORRECT
POSITIONING OF THE TUBE.
CAUTION: CORRECT POSI-
TIONING OF THE TUBE
pict. 7
