Datasheet

Technische Änderungen und Irrtümer vorbehalten. Subject to technical changes and errors.
Datum / Date: 03.2011 AS2 Revision: 1.0 Seite 1 von 1
Datenblatt / Data Sheet
Artikelnr.
Diameter
Length Color
Volts
AC/DC Base
Design Current
(mA)
Wave Length
(nm) Lumens
Life time
(h)
View
Angle
70112762 T6.8*43mm Red 12V T6.8G 18mA 620-630 0.8 lm 30K(h) 60°
70112766 T6.8*43mm Red 24-28V T6.8G 15mA 620-630 0.7 lm 30K(h) 60°
70112768 T6.8*43mm Red 30V T6.8G 14mA 620-630 0.6 lm 30K(h) 60°
70112774 T6.8*43mm Red 60V T6.8G 10mA 620-630 0.4 lm 30K(h) 60°
70112776 T6.8*43mm Red 70V T6.8G 9mA 620-630 0.4 lm 30K(h) 60°
70112780 T6.8*43mm Green 12V T6.8G 17mA 515-525 2 lm 30K(h) 60°
70112784 T6.8*43mm Green 24-28V T6.8G 14mA 515-525 1.7 lm 30K(h) 60°
70112786 T6.8*43mm Green 30V T6.8G 14mA 515-525 1.7 lm 30K(h) 60°
70112792 T6.8*43mm Green 60V T6.8G 10mA 515-525 1.2 lm 30K(h) 60°
70112794 T6.8*43mm Green 70V T6.8G 9mA 515-525 1.1 lm 30K(h) 60°
70112798 T6.8*43mm Blue 12V T6.8G 17mA 465-475 0.5 lm 30K(h) 60°
70112802 T6.8*43mm Blue 24-28V T6.8G 14mA 465-475 0.4 lm 30K(h) 60°
70112804 T6.8*43mm Blue 30V T6.8G 14mA 465-475 0.4 lm 30K(h) 60°
70112810 T6.8*43mm Blue 60V T6.8G 10mA 465-475 0.3 lm 30K(h) 60°
70112812 T6.8*43mm Blue 70V T6.8G 9mA 465-475 0.25 lm 30K(h) 60°
70112816 T6.8*43mm Amber 12V T6.8G 18mA 585-595 0.6 lm 30K(h) 60°
70112820 T6.8*43mm Amber 24-28V T6.8G 14mA 585-595 0.5 lm 30K(h) 60°
70112822 T6.8*43mm Amber 30V T6.8G 14mA 585-595 0.5 lm 30K(h) 60°
70112828 T6.8*43mm Amber 60V T6.8G 10mA 585-595 0.35 lm 30K(h) 60°
70112830 T6.8*43mm Amber 70V T6.8G 9mA 585-595 0.3 lm 30K(h) 60°
70112834 T6.8*43mm White 12V T6.8G 17mA (K)5000-6000 2.1 lm 30K(h) 60°
70112838 T6.8*43mm White 24-28V T6.8G 14mA (K)5000-6000 1.7 lm 30K(h) 60°
70112840 T6.8*43mm White 30V T6.8G 14mA (K)5000-6000 1.7 lm 30K(h) 60°
70112846 T6.8*43mm White 60V T6.8G 10mA (K)5000-6000 1.4 lm 30K(h) 60°
70112848 T6.8*43mm White 70V T6.8G 9mA (K)5000-6000 1.3 lm 30K(h) 60°
T6.8G Slide Base Lamp
